Waters ACQUITY UPLC M-Class - Ethernet Connections; Signal Connections; Connecting Signal Cables

µBSM
ASM
Power connectors
Ethernet connectors
C.2.1 Ethernet connections
The µSM-FL incorporates an internal 10/100/1000 megabit Ethernet switch that accommodates
the PC (workstation) and up to six system modules. Connect the shielded Ethernet cables from
each module to the electronic connections on the rear panel of the µSM-FL.
C.3 Signal connections
C.3.1 Connecting signal cables
Refer to the signal connection location shown on the silk-screened label affixed to the rear panel
of each system module.
C.3.1.1
Connecting signal cables
The module's rear panel includes a removable connector that holds the screw terminals for the
I/O signal cables. The connector is keyed to ensure that it is inserted only one way.
Required tools and materials
• 9/32-inch nut driver
• Flat-blade screwdriver
To connect the cables:
1. Insert the connector into the connector port on the module's rear panel.
November 26, 2019, 715003588 Revision C
Page 96
