Waters ACQUITY UPLC M-Class - B.5 Physical specifications

Table B–9: Power requirements
Attribute Specification
Power requirements 100 to 240 VAC
Line frequency 50 to 60 Hz
Power consumption ASM: 360 VA
µBSM: 360 VA
µSM-FL: 400 VA
SO: 540 VA
TVM: 150 VA
B.5
Physical specifications
The following table lists the physical specifications for the individual ACQUITY UPLC M-Class
system components.
Notes:
• Provide clearance of at least 15.2 cm (6 inches) on the back side of each component for
ventilation.
• Provide clearance of at least 7.6 cm (3 inches) on the right side of the µSM-FL for ventilation.
Table B–10: System components physical specifications
System
component
Depth Height Width Weight
ASM (including
the flow module)
66.1 cm
(26.0 inches)
23.8 cm
(9.38 inches)
41.9 cm
(16.5 inches)
28.6 kg
(63.0 pounds)
µBSM (including
the flow module)
66.1 cm
(26.0 inches)
23.8 cm
(9.38 inches)
41.9 cm
(16.5 inches)
28.6 kg
(63.0 pounds)
PDA detector 60.7 cm
(23.9 inches)
19.4 cm
(7.6 inches)
34.3 cm
(13.5 inches)
13.6 kg
(30.0 pounds)
Sample
organizer
(including base)
76.2 cm
(30.0 inches)
96.5 cm
(38.0 inches)
25.4 cm
(10.0 inches)
56.8 kg
(125.0 pounds)
µSM-FL 71.2 cm
(28.0 inches)
27.1 cm
(10.7 inches)
34.3 cm
(13.5 inches)
25.9 kg
(57.0 pounds)
Solvent tray 52.1 cm
(20.5 inches)
14 cm
(5.5 inches)
34.3 cm
(13.5 inches)
2.3 kg
(5.0 pounds)
TVM 61.0 cm
(24.0 inches)
16.5 cm
(6.5 inches)
34.3 cm
(13.5 inches)
15.9 kg
(35.0 pounds)
November 26, 2019, 715003588 Revision C
Page 92
