1.1.1 Examples of typical ACQUITY M-Class system configurations
Figure 1–1: Single-pump trapping configuration
Solvent tray
Trap valve manager
µSample manager - fixed loop
µBinary solvent manager
Figure 1–2: Dual-pump trapping configuration
Solvent tray
Trap valve manager
µSample manager - fixed loop
November 26, 2019, 715003588 Revision C
Page 13
