Run LED Depicts the actual run LED on the front panel, unless
communications to the µSM-FL are interrupted.
Warning indicator Displays the warning indicator icon when number of injections
threshold (set by the user) is exceeded.
Display console Launches the instrument console.
Column-temperature
set point
Displays the current column-temperature set point to 0.1 °C
resolution (column temperature controlled by the TVM). When
active temperature control is disabled, this field displays Off.
Sample-temperature
set point
Displays the current sample set point to 0.1 °C resolution. When
active temperature control is disabled, this field displays Off.
Sample temperature Displays the current sample temperature to 0.1°C resolution, even
when active temperature control is disabled.
Status Displays the status of the current operation.
You can access these additional functions by right-clicking anywhere in the µSM-FL control panel.
Table 3–6: Additional functions in the µSM-FL control panel
Control panel function Description
Prime syringes Displays the Prime dialog box.
See also: “Priming the µSM-FL” in the
µSample Manager - Fixed Loop Overview and
Maintenance Guide.
Wash needle Displays the Wash Needle dialog box.
See also: “Washing the µSM-FL needle” in
the µSample Manager - Fixed Loop Overview
and Maintenance Guide.
Turn lights on/off Lights power-on only when the sample
manager door is open.
Reset SM Resets the µSM-FL following an error
condition.
Help Displays the instrument console’s online Help.
November 26, 2019, 715003588 Revision C
Page 55
