USER GUIDE – WebdynSunPM
WebdynSunPM – User guide — Version 1.0
6 Interfaces
6.1 Power supply
The WebdynSunPM concentrator can be powered using 12 or 24V DC. The power supply is the two-
point plug-in terminal block located at the top left of the box.
Ensure you observe the wiring directions of the power supply.
Mass
12 / 24 V terminal
Power consumption varies according to product configuration and the devices connected to it. Make
sure that the power supply used can provide 10 W.
6.1.1 Battery
The WebdynSunPM concentrator has a lithium battery for managing micro-outages and sending
alarms in the event of a power failure.
Note: The battery recharges via the external power supply. Pay close attention to the charge during
frequent or long power cuts as the battery may not have time to recharge. If this occurs, the power
loss alarm cannot be sent immediately: it will be sent upon restart.
1
2
