WebdynSunPM – User guide — Version 1.0
Each block is composed of a header and a body containing time-stamped data.
The header takes two or three lines, and adheres to the following format. Green text
indicates the information that only appears if the variable "DAQ_HeaderOption" in the file
"xxxxxx_daq.ini" is set to "1".
Where:
Addr: Modbus address
NumDevice: device number
FileDefName: device definition file
DeviceId: device identification
nbVar: number of variables collected
id1;id2…idn: identities of variables collected
The body section contains time-stamped data in the following format:
The number of values per line depends on the number of variables collected for the device,
and therefore on the definition file associated with the device.
ADDRMODBUS;Addr;NumDevice
TypeMODBUS;FileDefName;DeviceId
nbVar;id1;id2;… ;idn
DD/MM/AA-hh:mm:ss;value1;value2;….;valuen
DD/MM/AA-hh:mm:ss;value1;value2;….;valuen
…
DD/MM/AA-hh:mm:ss;value1;value2;….;valuen
