Table 8.3 - Technical specications of the CFW-11 inverter series frame sizes F and G models at 5 kHz switching frequency
Model
CFW11
0242
T 4
CFW11
0312
T 4
CFW11
0370
T 4
CFW11
0477
T 4
CFW11
0515
T 4
CFW11
0601
T 4
CFW11
0720
T 4
Frame Size F G
Number of Power Phases 3Φ
Use with Normal
Duty (ND) Cycle
Rated output current
(1)
[Arms] 175 225 266 343 343 390 468
Overload Current
[Arms]
1 min 193 248 293 377 377 429 515
3 s 263 338 399 515 515 585 702
Rated Switching Frequency [kHz] 5.0 5.0 5.0 5.0 5.0 5.0 5.0
Maximum Motor
(2)
[HP/kW] 150/110 175/132 200/150 270/200 270/200 300/220 400/300
Rated Input Current [Arms] 175 225 266 343 343 390 468
Dissipated Power
[W]
Surface Mounting
(3)
2154 2770 3274 4222 4222 4801 5761
Flange Mounting
(4)
819 1053 1245 1605 1605 1825 2190
Use with Heavy
Duty (HD) Cycle
Rated Output Current
(1)
[Arms] 152 175 225 266 318 335 364
Overload Current
[Arms]
1 min 228 263 338 400 477 503 546
3 s 304 350 450 532 636 670 728
Rated Switching Frequency [kHz] 5.0 5.0 5.0 5.0 5.0 5.0 5.0
Maximum Motor
(2)
[HP/kW] 125/90 150/110 175/132 200/150 250/185 270/200 300/220
Rated Input Current [Arms] 152 175 225 266 318 335 364
Dissipated Power
[W]
Surface Mounting
(3)
1871 2154 2770 3274 3914 4124 4481
Flange Mounting
(4)
711 819 1053 1245 1488 1568 1703
Surrounding Air Temperature [°C]
(1)
-10...40 -10...40 -10...40 -10...40 -10...40 -10...40 -10...40
RFI Filter Built-in
Weight [kg (lb)] 130 132 135 140 204 207 215
Availability of
Option Kits that
can be Integrated
into the
Product (refer to
the smart code
in the Section 2.5
HOW TO SPECIFY
THE CFW-11
MODEL (SMART
CODE) on page
2-14)
Safety Stop Yes
24 Vdc External
Control
Power Supply
Yes
(1) Steady state rated current in the following conditions:
- 5 kHz switching frequency.
- Surrounding air temperature as specified in the table. For higher temperatures, limited to 50 ºC (122 °F), the output current must be derated by 2 %
for each ºC above the maximum specified temperature.
- Air relative humidity: 5 % to 90 % non-condensing.
- Altitude: 1000 m (3.300 ft). Above 1000 m (3.300 ft) up to 4000 m (13.200 ft) the output current must be derated by 1 % for each 100 m (330 ft)
above 1000 m (3.300 ft).
- Ambient with pollution degree 2 (according to EN50178 and UL508C).
(2) The motor outputs are only for guiding purposes for WEG motor 460 V, 4 poles. The proper sizing must be done according to the rated current of the
motors used.
(3) The dissipated powers are valid for rated operating conditions, that is, for rated output current and switching frequency.
(4) The dissipated powers for flange mounting correspond to the total losses of the inverter minus the losses on the power modules (IGBT and rectifier).
