Installation and Connection
3
3-10 | CFW-11
U/T1
R/L1
V/T2
S/L2
W/T3
T/L3
(c) Frame size G power terminals and grounding points
DC-
DC+
(d) Frame size G with special DC hardware: Terminals for DC voltage supply. Terminals R/L1, S/L2 and T/L3 are not internally
connected in this version
Figure 3.7 - (a) to (d) - Grounding and power terminals of frame sizes F and G
