WEG CFW-11 - Page 42

Installation and Connection
3
3-16 | CFW-11
Table 3.3 - Recommended Wiring/Fuses for models with DC power supply (special DC Hardware) – use copper wiring only
(75 °C) (167 ºF)
Model
Frame Size
Power Terminals
Duty
Cycle
Wiring
Fuse
[A]
Fuse I2t
@ 25 ºC
Terminals
[A2s]
Terminals
Bolt
(wrench/bolt
head type)
Recommended
Torque N.m
(lbf.in)
mm
2
AWG Terminals
CFW110242T4DC
F
U/T1 - V/T2 - W/T3
M12 (Phillips
hex head)
60 (531.00)
HD 2 x 50 2 x 1/0
Ring
tongue
420
See
note
(2)
ND 2 x 70 2 x 1/0
DC+, DC-
M12 (Phillips
hex head)
60 (531.00) HD/ND 2 x 95 2 x 3/0
M8 (Phillips
hex head)
10 (88.5) HD/ND 70 1/0
CFW110312T4DC
U/T1 - V/T2 - W/T3
M12 (Phillips
hex head)
60 (531.00)
HD 2 x 70 2 x 1/0
Ring
tongue
540
See
note
(2)
ND 2 x 120 2 x 4/0
DC+, DC-
M12 (Phillips
hex head)
60 (531.00) HD/ND 2 x 120 2 x 4/0
M8 (Phillips
hex head)
10 (88.5) HD/ND 120 4/0
CFW110370T4DC
U/T1 - V/T2 - W/T3
M12 (Phillips
hex head)
60 (531.00)
HD 2 x 120 2 x 4/0
Ring
tongue
640
See
note
(2)
ND 2 x 120 2 x 4/0
DC+, DC-
M12 (Phillips
hex head)
60 (531.00) HD/ND 2 x 150 2 x 300
M8 (Phillips
hex head)
10 (88.5) HD/ND 120 4/0
CFW110477T4DC
U/T1 - V/T2 - W/T3
M12 (Phillips
hex head)
60 (531.00)
HD 2 x 120 2 x 4/0
Ring
tongue
830
See
note
(2)
ND 2 x 185 2 x 350
DC+, DC-
M12 (Phillips
hex head)
60 (531.00) HD/ND 2 x 240 2 x 500
M8 (Phillips
hex head)
10 (88.5) HD/ND 185 350
CFW110515T4DC
G
U/T1 - V/T2 - W/T3
M12 (Phillips
hex head)
60 (531.00)
HD 3 x 120 3 x 4/0
Ring
tongue
890
See
note
(2)
ND 3 x 120 3 x 4/0
DC+, DC-
M12 (Phillips
hex head)
60 (531.00) HD/ND 3 in
(1)
76 mm
(1)
M8 (Phillips
hex head)
10 (88.5) HD/ND 120 4/0
CFW110601T4DC
U/T1 - V/T2 - W/T3
M12 (Phillips
hex head)
60 (531,00)
HD 3 x 120 3 x 4/0
Ring
tongue
1035
See
note
(2)
ND 3 x 150 3 x 300
DC+, DC-
M12 (Phillips
hex head)
60 (531.00) HD/ND 3 in
(1)
76 mm
(1)
M8 (Phillips
hex head)
10 (88.5) HD/ND 150 300
CFW110720T4DC
U/T1 - V/T2 - W/T3
M12(Phillips
hex head)
60 (531.00)
HD 3 x 120 3 x 4/0
Ring
tongue
1245
See
note
(2)
ND 3 x 185 3 x 350
DC+, DC-
M12 (Phillips
hex head)
60 (531.00) HD/ND 4 in
(1)
102 mm
(1)
M8 (Phillips
hex head)
10 (88.5) HD/ND 185 350
CFW110760T4DC
U/T1 - V/T2 - W/T3
M12 (Phillips
hex head)
60 (531.00)
HD 3 x 150 3 x 300
Ring
tongue
1245
See
note
(1)
ND 3 x 185 3 x 500
DC+, DC-
M12 (Phillips
hex head)
60 (531.00) HD/ND 4 in
(1)
102 mm
(1)
M8 (Phillips
hex head)
10 (88.5) HD/ND 185 500
