QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P245 Potentiometer and FI1 Filter 0.00 to 16.00 s 9-6
P246 FI1 Input Function 0 = Inactive
1 = Active in DI1
2 = Active in DI2
3 = Active in DI3
4 = Active in DI4
cfg 9-11
P247 FI1 Input Gain 0.000 to 9.999 9-11
P248 FI1 Minimum Input 1 to 3000 Hz 9-11
P249 FI1 Input Offset -100.0 to 100.0 % 9-11
P250 FI1 Maximum Input 1 to 3000 Hz 9-11
P251
(*)
AO1 Output Function 0 = Speed Ref.
1 = Not Used
2 = Real Speed
3 to 4 = Not Used
5 = Output Current
6 = Not Used
7 = Active Current
8 to 10 = Not Used
11 = Motor Torque
12 = SoftPLC
13 to 15 = Not Used
16 = Motor Ixt
17 = Not Used
18 = P696 Value
19 = P697 Value
20 = Not Used
21 = Application Function 1
22 = Application Function 2
23 = Application Function 3
24 = Application Function 4
25 = Application Function 5
26 = Application Function 6
27 = Application Function 7
28 = Application Function 8
29 = Control Setpoint
30 = Process Variable
9-7
P252
(*)
AO1 Output Gain 0.000 to 9.999 9-8
P253
(*)
AO1 Output Signal 0 = 0 to 10 V
1 = 0 to 20 mA
2 = 4 to 20 mA
3 = 10 V to 0
4 = 20 mA to 0
5 = 20 to 4 mA
9-9
P254
(*)
AO2 Output Function See options in P251 9-8
P255
(*)
AO2 Output Gain 0.000 to 9.999 9-8
P256
(*)
AO2 Output Signal See options in P253 9-9
