9
I/O
P254 - AO2 Output Function
Range: 0 = Speed Ref.
1 = Not Used
2 = Real Speed
3 to 4 = Not Used
5 = Output Current
6 = Not Used
7 = Active Current
8 to 10 = Not Used
11 = Motor Torque
12 = SoftPLC
13 to 15 = Not Used
16 = Motor Ixt
17 = Not Used
18 = P696 Value
19 = P697 Value
20 = Not Used
21 = Application Function 1
22 = Application Function 2
23 = Application Function 3
24 = Application Function 4
25 = Application Function 5
26 = Application Function 6
27 = Application Function 7
28 = Application Function 8
29 = Control Setpoint
30 = Process Variable
Description:
These parameters sets the functions of the analog outputs, according to function and scale presented in Table 9.2
on page 9-8.
Table 9.2: Full scale of the analog output
Function Description Full Scale
0 Speed reference at the input of the ramp P001 P134
2 Effective speed at the inverter output P134
5 Total output current RMS 2 x P295
7 Active Current 2 x P295
11 Torque on the motor in relation to the rated torque 200,0 %
12 SoftPLC scale for analog output 32767
16 Ixt overload of the motor (P037) 100 %
18 Value of P696 for analog output AOx 32767
19 Value of P697 for analog output AOx 32767
21 to 28 Value defined by the SoftPLC application 32767
29 Control Setpoint (PID Controller Application) (*)
30 Process Variable (PID Controller Application) (*)
(*) For further details refer the Chapter 14 APPLICATIONS on page 14-1.
P252 - AO1 Output Gain
P255 - AO2 Output Gain
Range: 0.000 to 9.999
9-8 | Micro Mini Drives
