QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P223 LOC FWD/REV Selection 0 = Foward
1 = Reverse
2 to 3 = Not Used
4 = DIx
5 = Serial/USB (FWD)
6 = Serial/USB (REV)
7 to 8 = Not Used
9 = CO/DN/DP/ETH (FWD)
10 = CO/DN/DP/ETH (REV)
11 = Not Used
12 = SoftPLC
cfg 7-5
P224 LOC Run/Stop Sel. 0 = HMI Keys
1 = DIx
2 = Serial/USB
3 = Not Used
4 = CO/DN/DP/ETH
5 = SoftPLC
cfg 7-5
P225 LOC JOG Selection 0 = Disabled
1 = Not Used
2 = DIx
3 = Serial/USB
4 = Not Used
5 = CO/DN/DP/ETH
6 = SoftPLC
cfg 7-6
P226 REM FWD/REV Selection See options in P223 cfg 7-5
P227 REM Run/Stop Selection See options in P224 cfg 7-5
P228 REM JOG Selection See options in P225 cfg 7-6
P229 Stop Mode Selection 0 = Ramp to Stop
1 = Coast to Stop
cfg 7-6
P230 Dead Zone (AIs and FI1 ) 0 = Inactive
1 = Active
cfg 9-1
P231 AI1 Signal Function 0 = Speed Ref.
1 to 3 = Not Used
4 = PTC
5 to 6 = Not Used
7 = PLC Use
8 = Application Function 1
9 = Application Function 2
10 = Application Function 3
11 = Application Function 4
12 = Application Function 5
13 = Application Function 6
14 = Application Function 7
15 = Application Function 8
16 = Control Setpoint
17 = Process Variable
cfg 9-2
P232 AI1 Input Gain 0.000 to 9.999 9-3
P233 AI1 Input Signal 0 = 0 to 10 V / 20 mA
1 = 4 to 20 mA
2 = 10 V / 20 mA to 0
3 = 20 to 4 mA
9-3
P234 AI1 Input Offset -100.0 to 100.0 % 9-4
P235 AI1 Input Filter 0.00 to 16.00 s 9-4
P236
(*)
AI2 Signal Function See options in P231 cfg 9-2
P237
(*)
AI2 Input Gain 0.000 to 9.999 9-3
P238
(*)
AI2 Input Signal See options in P233 9-3
P239
(*)
AI2 Input Offset -100.0 to 100.0 % 9-4
P240
(*)
AI2 Input Filter 0.00 to 16.00 s 9-5
P241
(*)
Potentiometer Signal Function 0 = Speed Ref.
1 to 6 = Not Used
7 = SoftPLC
8 = Application Function 1
9 = Application Function 2
10 = Application Function 3
11 = Application Function 4
12 = Application Function 5
13 = Application Function 6
14 = Application Function 7
15 = Application Function 8
16 to 17 = Not Used
cfg 9-6
P242
(*)
Potentiometer Signal Gain 0.000 to 9.999 9-6
P244
(*)
Potentiometer Signal Offset -100.0 to 100.0 % 9-6
