QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P150 DC/LC Regul. Type 0 = hold_Ud and decel_LC
1 = accel_Ud and decel_LC
2 = hold_Ud and hold_LC
3 = accel_Ud and hold_LC
cfg, V/f, VVW 8-3
P151 DC Link Regul. Level 325 to 810 V V/f, VVW 8-5
P153 Dynamic Braking Level 348 to 800 V V/f, VVW 8-12
P156 Rated Speed Overload Current 0.1 to 40.0 A 10-5
P157 Overl.Curr.50 % Speed 0.1 to 40.0 A 10-5
P158 Overl.Curr.20 % Speed 0.1 to 40.0 A 10-5
P178 Rated Flux 50.0 to 150.0 % VVW 8-32
P200 Password 0 = Inactive
1 = Active
2 to 9999 = New Password
cfg 5-1
P202 Type of Control 0 = V/f
1 = Quadratic V/f
2 to 4 = Not Used
5 = VVW
cfg 8-1
P204 Load/Save Parameters 0 to 4 = Not Used
5 = Load 60Hz
6 = Load 50Hz
7 = Load User
8 = Not Used
9 = Save User
10 = Not Used
11 = Load Default SoftPLC
12 to 13 = Reserved
cfg 5-2
P205 Main Display Parameter 0 to 999 5-3
P207 Bar Graph Parameter 0 to 999 5-3
P208 Ref. Scale Factor 1 to 9999 5-3
P209 Ref. Eng. Unit 0 to 1 = Without unit
2 = Volt (V)
3 = Hertz (Hz)
4 = Without unit
5 = Percent (%)
6 = Without unit
7 = Rotation/min. (rpm)
5-3
P210 Ref. Decimal Point 0 = wxyz
1 = wxy.z
2 = wx.yz
3 = w.xyz
5-4
P213 Bar Scale Factor 1 to 9999 5-4
P219 Red. Switch. Freq. 0.0 to 15.0 Hz cfg 8-8
P220 LOC/REM Selection Source 0 = Always Local
1 = Always Remoto
2 to 3 = Not Used
4 = DIx
5 = Serial/USB (LOC)
6 = Serial/USB (REM)
7 to 8 = Not Used
9 = CO/DN/DP/ETH (LOC)
10 = CO/DN/DP/ETH (REM)
11 = SoftPLC
cfg 7-4
P221 LOC Reference Sel. 0 = HMI
1 = AI1
2 = AI2
3 = Potentiometer
4 = FI
5 = AI1 + AI2 > 0
6 = AI1 + AI2
7 = E.P.
8 = Multispeed
9 = Serial/USB
10 = Not Used
11 = CO/DN/DP/ETH
12 = SoftPLC
13 = Not Used
14 = AI1 > 0
15 = AI2 > 0
16 = Potentiometer > 0
17 = FI > 0
cfg 7-4
P222 REM Reference Selection See options in P221 cfg 7-4
Micro Mini Drives | 0-9
