QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P037 Motor Overload Ixt 0.0 to 100.0 % ro 10-4
P038
(*)
Encoder Speed -9999 to 9999 rpm ro 11-4
P039
(*)
Encoder Pulses Count 0 to 9999 ro 11-4
P045 Fan Enabled Time 0 to FFFF (hexa) ro 11-5
P047 CONF Status 0 to 33 (Table 11.2 on page 11-5) ro 11-5
P048 Present Alarm 0 to 999 ro 10-1
P049 Present Fault 0 to 999 ro 10-1
P050 Last Fault 0 to 999 ro 10-1
P051 Current At Last Fault 0.0 to 40.0 A ro 10-1
P052 DC Link At Last Fault 0 to 828 V ro 10-1
P053 Frequency At Last Fault 0.0 to 400.0 Hz ro 10-2
P054 Temperature Last Fault 0.0 to 200.0 ºC ro 10-2
P060 Second Fault 0 to 999 ro 10-1
P070 Third Fault 0 to 999 ro 10-1
P080 Last Fault on Fire Mode 0 to 999 ro 10-2
P081 Second Fault on Fire Mode 0 to 999 ro 10-2
P082 Third Fault on Fire Mode 0 to 999 ro 10-2
P100 Acceleration Time 0.1 to 999.9 s 8-2
P101 Deceleration Time 0.1 to 999.9 s 8-2
P102 Acceleration Time 2nd Ramp 0.1 to 999.9 s 8-2
P103 Deceleration Time 2nd Ramp 0.1 to 999.9 s 8-2
P104 Ramp S 0 = Inactive
1 = Active
cfg 8-2
P105 1st / 2nd Ramp Selection 0 = 1st Ramp
1 = 2nd Ramp
2 = DIx
3 = Serial/USB
4 = Reserved
5 = CO/DN/DP/ETH
6 = SoftPLC
8-3
P106 Emer. R. Acceleration Time 0.1 to 999.9 s 8-2
P107 Emer. R. Time Deceleration 0.1 to 999.9 s 8-2
P120 Speed Ref. Backup 0 = Inactive
1 = Active
2 = Backup by P121
7-7
P121 Reference via HMI 0.0 to 400.0 Hz 7-7
P122 JOG Reference -400.0 to 400.0 Hz 7-8
P124 Multispeed Ref. 1 -400.0 to 400.0 Hz 7-8
P125 Multispeed Ref. 2 -400.0 to 400.0 Hz 7-8
P126 Multispeed Ref. 3 -400.0 to 400.0 Hz 7-8
P127 Multispeed Ref. 4 -400.0 to 400.0 Hz 7-8
P128 Multispeed Ref. 5 -400.0 to 400.0 Hz 7-8
P129 Multispeed Ref. 6 -400.0 to 400.0 Hz 7-8
P130 Multispeed Ref. 7 -400.0 to 400.0 Hz 7-8
P131 Multispeed Ref. 8 -400.0 to 400.0 Hz 7-8
P133 Minimum Frequency 0.0 to 400.0 Hz 7-9
P134 Maximum Frequency 0.0 to 400.0 Hz 7-9
P135 Maximum Output Current 0.0 to 40.0 A V/f 8-7
P136 Manual Torque Boost 0.0 to 30.0 % V/f 8-21
P137 Automatic Torque Boost 0.0 to 30.0 % V/f 8-22
P138 Slip Compensation -10.0 to 10.0 % V/f 8-22
P139 Output Current Filter 0.000 to 9.999 s V/f, VVW 8-8
P140 Slip Com. Filter 0.000 to 9.999 s VVW 8-31
P142 Maximum Output Voltage 0.0 to 100.0 % cfg, V/f 8-23
P143 Intermediate Output Voltage 0.0 to 100.0 % cfg, V/f 8-23
P145 Field Weakening Speed 0.0 to 400.0 Hz cfg, V/f 8-23
P146 Intermediate Frequency 0.0 to 400.0 Hz cfg, V/f 8-23
P149 DC Link Comp. Mode 0 = Inactive
1 = Standard
2 = Overmodulation
3 = Extended
cfg, V/f 8-4
0-8 | Micro Mini Drives
