QUICK REFERENCE OF PARAMETERS
QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P000 Access to Parameters 0 to 9999 5-1
P001 Speed Reference 0 to 9999 ro 11-1
P002 Output Speed (Motor) 0 to 9999 ro 11-1
P003 Motor Current 0.0 to 40.0 A ro 11-1
P004 DC Link Voltage 0 to 828 V ro 11-1
P005 Output Frequency (Motor) 0.0 to 400.0 Hz ro 11-1
P006 Inverter Status 0 = Ready
1 = Run
2 = Undervoltage
3 = Fault
4 = Self-Tuning
5 = Configuration
6 = DC Braking
7 = Reserved
8 = Fire Mode
ro 11-2
P007 Output Voltage 0 to 480 V ro 11-3
P009 Motor Torque -200.0 to 200.0 % ro, VVW 11-4
P011 Power Factor 0.00 to 1.00 ro 8-24
P012 DI8 to DI1 Status 0 to FF (hexa)
Bit 0 = DI1
Bit 1 = DI2
Bit 2 = DI3
Bit 3 = DI4
Bit 4 = DI5
Bit 5 = DI6
Bit 6 = DI7
Bit 7 = DI8
ro 9-12
P013 DO4 to DO1 Status 0 to F (hexa)
Bit 0 = DO1
Bit 1 = DO2
Bit 2 = DO3
Bit 3 = DO4
ro 9-20
P014
(*)
AO1 Value 0.0 to 100.0 % ro 9-7
P015
(*)
AO2 Value 0.0 to 100.0 % ro 9-7
P018 AI1 Value -100.0 to 100.0 % ro 9-1
P019
(*)
AI2 Value -100.0 to 100.0 % ro 9-1
P020
(*)
Potentiometer Signal Value -100.0 to 100.0 % ro 9-5
P022 FI Value in Hz 0 to 3000 Hz ro 9-10
P023 Main SW Version 0.00 to 99.99 ro 6-1
P024
(*)
IO Acces. SW Version 0.00 to 99.99 ro 6-3
P025
(*)
Comm. Acces. SW Version 0.00 to 99.99 ro 6-3
P027 Config. Acces. IO 0 to 10 ro 6-3
P028 Config. Comm. Acces. 0 to 10 ro 6-3
P029 Power HW Configuration 0 = Not identified
1 = 1.6A/110V
2 = 2.6A/110V
3 = 4.2A/110V
4 = 6.0A/110V
5 = 1.6A/220V
6 = 2.6A/220V
7 = 4.2A/220V
8 = 6.0A/220V
9 = 7.3A/220V
10 = 10.0A/220V
11 = 15.2A/220V
12 to 19 = Reserved
20 = 1.1A/380V
21 = 1.8A/380V
22 = 2.6A/380V
23 = 3.5A/380V
24 = 4.8A/380V
25 = 6.5A/380V
26 = 8.2A/380V
27 = 10.0A/380V
28 = 12.0A/380V
29 = 15.0A/380V
ro 6-1
P030 Module Temperature -200.0 to 200.0 ºC ro 11-4
Micro Mini Drives | 0-7
