COMMAND AND REFERENCES
Besides, the P121 is used as input for the reference backup function.
NOTE!
The minimum and maximum values of parameter setting are limited by P134 and P133, respectively.
P122 - JOG Reference
Range: -400.0 to 400.0 Hz
Description:
During the JOG command, the motor accelerates up to the value defined in P122, following the acceleration ramp
set according to P105. This command may be activated by any of the sources, as per Section 7.1 REFERENCE
SOURCE SELECTION on page 7-1. The negative values determine a direction of rotation opposite to that defined
by the inverter command word.
P124 - Multispeed Ref. 1
P125 - Multispeed Ref. 2
P126 - Multispeed Ref. 3
P127 - Multispeed Ref. 4
P128 - Multispeed Ref. 5
P129 - Multispeed Ref. 6
P130 - Multispeed Ref. 7
P131 - Multispeed Ref. 8
Range: -400.0 to 400.0 Hz
Description:
By the combination of up to three digital inputs, one from eight levels that form the multispeed reference is selected.
Read the description of the of the digital inputs in Section 9.6 DIGITAL INPUTS on page 9-11, as well the reference
selection in Section 7.1 REFERENCE SOURCE SELECTION on page 7-1. The negative values determine a direction
of rotation opposite to that defined by the inverter command word (bit 2 of P682).
Figure 7.3 on page 7-9 and Table 7.4 on page 7-9 show the operation of the Multispeed. Although the most
significant digital input may be set at DI1 or DI2, only one of those options is allowed; otherwise, the Config state
(ConF), according to Table 11.2 on page 11-5, is activated to indicate parameterization incompatibility.
7-8 | Micro Mini Drives
