WEG CFW501 - Page 148

CFW501 | 143
Appendix B / Anexo B
Appendix B
Anexo B
136.2 [5.4]
206 [8.1]
5.8 [0.2]
6.5 [0.3]
5.3 [0.2]
R4 [0.2]
16.8 [0.7]
100 [3.9]
6.4 [0.3]
6.2 [0.2]
B
A
B
210 [8.3]
19 5 [ 7.7]
9.7 [0.4]
106.1 [4.2]
100 [3.9]
165.1 [6.5]
96 [3.8]
135.2 [5.3]
92 [3.6]
46.7 [1.8]
16.7 [0.7]
A
Figure B.6: Inverter dimensions in mm [in] – frame C
Figura B.6: Dimensiones del convertidor de frecuencia en mm [in] – tamaño C
Figura B.6: Dimensões do inversor em mm [in] – mecânica C
