144 | CFW501
Appendix B / Anexo B
Appendix B
Anexo B
128.5 [5.1]
305.7 [12]
306.6 [12.1]
R4 [0.2]
A
B
290 [11.4]
9.8 [0.4]
99.6 [3.9]
125 [4.9]
166.4 [6.6]
86.7 [3.4]
18 0 [ 7.1]
84 [3.3]
42.6 [1.7]
125 [4.9]
5.9 [0.2]
8 [0.3]
26.8 [1.1]
26.8 [1.1]
7.2 [0.3]
7.2 [0.3]
B
10.1 [0.4]
A
Figure B.7: Inverter dimensions in mm [in] – frame D
Figura B.7: Dimensiones del convertidor de frecuencia en mm [in] – tamaño D
Figura B.7: Dimensões do inversor em mm [in] – mecânica D
