ENGLISH
19.2. MIW-02:
External module for conversion from RS-232 to RS-485: it allows the connection of the SSW-05 to a standard RS-485
line. So the Soft-Starter can participate in a multipoint line up to 1000m (3280ft) without the use of transducers.
For more details about this connection, see the MIW-02 USER MANUAL (0899.4430), available for download on the
website www.weg.com.br .
Figure 19.2 - Connection of the SSW-05 to a standard RS-485 communication network.
Weg Network
RS-485
MIW-02
SSW-05 RJ Connector
Serial Port RS-232
RS-485
RS-232
19.3. HMI-SSW05-RS:
Remote serial keypad: this interface is mounted external to the Soft-Starter and can be used in the following cases:
applications that require a remote keypad;
installation on panel door;
when the keypad copy function is required for the transfer of parameter values from one Soft-Starter to another.
It operates with the cable CAB-RS-X, which length must be chosen according to the needs (up to 9.84ft).
Figure 19.3 - Dimensions of the HMI-SSW05-RS.
