INTRODUCTION
Section WDP-4602MXV
Camera
Image Sensor Sony IMX122 1/3” 2Megapixel CMOS
Scanning System Progressive Scan
Lens F2.0 f=4.3mm Fixed Corn Lens
Electronic Shutter
Speed
Auto / Flk
NTSC : 1/30sec ~ 1/50,000sec,
PAL : 1/25sec ~ 1/50,000sec
White Balance AWB / MANUAL / INDOOR / OUTDOOR
Backlight
Compensation
BLC / HLC / Off
ACCE Low / Middle / High / Off
AGC Low / Middle / High
Day & Night Auto / BW / Color
2D/3D-NR 2DNR / 3DNR / SMART NR
S/N Ratio More than 50dB
Min. Illumination
1.0Lux(Color) , 0.5Lux(BW) , 0.02Lux
(Sens-up x60)
Video
Compression H.264 @HP, MJPEG
Streaming
Simultaneous multiple streams
H.264 streaming over UDP,TCP,HTTP or HTTPS
MJPEG streaming over HTTP or HTTPS
Resolution
640x480, 800x480, 800x600, 1024x768,
1024x720, 1280x1024, 1920x1080
Frame Rate ⑵
up to 30fps @1080p
Output NTSC/PAL 1Vp-p 75ohm composite
