Configuration
- EVENT
42
This document contains confidential and proprietary information of Weldex Corporation.
WEB Viewer
• SENSOR INPUT
Sensor input can trigger alarm output, alarm sound output, FTP/SMTP image transmissions.
Item Description
Use
Enable/Disable sensor input.
Type
Configure
Sensor type.
Selectable values: NORMAL OPEN, NORMAL CLOSE.
On Sensor
Behavior
Configure sensor trigger behavior.
Upload JPEG image to FTP server
Upload JPEG images to the FTP server for the selected duration.
Selectable values: OFF, 10s, 30s, 1m, 5m, 10m.
Send email with JPEG image
Send JPEG images to the SMTP server for the selected duration.
Selectable values: OFF, 10s, 30s, 1m, 5m, 10m.
Alarm output
Outputs alarm signal for the selected duration.
Selectable values: OFF, 10s, 30s, 1m, 5m, 10m.
Play
alarm sound
Outputs alarm sound for the selected duration.
Selectable values: OFF, 10s, 30s, 1m, 5m, 10m.
