Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 129
6 Control 2 Setpoint Selection
7 Control 1 Pretune Enable/Disable
8 Control 2 Pretune Enable/Disable
9 Control 1 Selftune Enable/Disable
10 Control 2 Selftune Enable/Disable
11 Clear All Latched Outputs
12 Recorder Digital Start/Stop Trigger
13 Profile Run/Hold
14 Profile Abort
15 Profile Hold Release
16 Force Output 1 on/off
17 Force Output 2 on/off
18 Force Output 2B on/off
19 Force Output 3 on/off
20 Force Output 3B on/off
21 Force Output 4 on/off
22 Force Output 5 on/off
23 Output 1 Clear Latch
24 Output 2 Clear Latch
25 Output 2B Clear Latch
26 Output 3 Clear Latch
27 Output 3B Clear Latch
28 Output 4 Clear Latch
29 Output 5 Clear Latch
30 Up Key Press Mimic
31 Down Key Press Mimic
32 Back Key Press Mimic
33 Right Key Press Mimic
Soft Digital 1 Usage Value Usage for "Soft" Digital Input S1
Dec 10036 26420 52840
RW
0 Unused
Hex 2734 6734 CE68
1 Control 1 Enable Disable
2 Control 2 Enable Disable
3 Control 1 Auto/Manual
4 Control 2 Auto/Manual
5 Control 1 Setpoint Selection
6 Control 2 Setpoint Selection
7 Control 1 Pretune Enable/Disable
8 Control 2 Pretune Enable/Disable
9 Control 1 Selftune Enable/Disable
10 Control 2 Selftune Enable/Disable
11 Clear All Latched Outputs
12 Recorder Digital Start/Stop Trigger
13 Profile Run/Hold
14 Profile Abort
15 Profile Hold Release
16 Force Output 1 on/off
17 Force Output 2 on/off
18 Force Output 2B on/off
19 Force Output 3 on/off
20 Force Output 3B on/off
