Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 130
21 Force Output 4 on/off
22 Force Output 5 on/off
23 Output 1 Clear Latch
24 Output 2 Clear Latch
25 Output 2B Clear Latch
26 Output 3 Clear Latch
27 Output 3B Clear Latch
28 Output 4 Clear Latch
29 Output 5 Clear Latch
30 Up Key Press Mimic
31 Down Key Press Mimic
32 Back Key Press Mimic
33 Right Key Press Mimic
Soft Digital 1 OR Digital Inputs Bit If Bit value = 1 Input n Is Included in OR Selection
Dec 10040 26424 52848
RW
0 Digital Input A
Hex 2738 6738 CE70
1 Digital Input C1
2 Digital Input C2
3 Digital Input C3
4 Digital Input C4
5 Digital Input C5
6 Digital Input C6
7 Digital Input C7
8 Digital Input C8
Soft Digital 1 AND Digital Inputs Bit If Bit value = 1 Input n Is Included in AND Selection
Dec 10041 26425 52850
RW
0 Digital Input A
Hex 2739 6739 CE72
1 Digital Input C1
2 Digital Input C2
3 Digital Input C3
4 Digital Input C4
5 Digital Input C5
6 Digital Input C6
7 Digital Input C7
8 Digital Input C8
Soft Digital 1 OR Alarms Bit If Bit value = 1 Alarm n Is Included in OR Selection
Dec 10050 26434 52868
RW
0 Alarm 1
Hex 2742 6742 CE84
1 Alarm 2
2 Alarm 3
3 Alarm 4
4 Alarm 5
5 Alarm 6
6 Alarm 7
Soft Digital 1 OR Events Bit If Bit value = 1 Event n Is Included in OR Selection
Dec 10051 26435 52870
RW
0 Event 1
Hex 2743 6743 CE86
1 Event 2
2 Event 3
3 Event 4
4 Event 5
5 Profile Running
6 Profile End
To Next Page
