Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 153
Loop 1 Primary Power Upper limit Loop 1 Primary Power Upper limit
Dec 4321 20705 41410
RW
10 to 100%
but must be at least 10% above the primary power lower limit.
Hex 10E1 50E1 A1C2
Loop 1 Primary Power Lower Limit Loop 1 Primary Power Lower Limit
Dec 4322 20706 41412
RW
0 to 90%
but must be at least 10% below the primary power upper limit.
Hex 10E2 50E2 A1C4
Loop 1 Secondary Upper Power limit Loop 1 Secondary Upper Power limit
Dec 4323 20707 41414
RW
10 to 100%
but must be at least 10% above the secondary power lower limit.
Hex 10E3 50E3 A1C6
Loop 1 Secondary Power Lower limit Loop 1 Secondary Power Lower limit
Dec 4324 20708 41416
RW
0 to 90%
but must be at least 10% below the primary power upper limit.
Hex 10E4 50E4 A1C8
Loop 1 Pre-Tune Method Value Pre-tune type
Dec 4396 20780 41560
RW
0 Standard
Hex 112C 512C A258
1 Pretune at Value
Loop 1 Pretune at Value Value To Pre-tune Loop 1
Dec 4399 20783 41566
RW
Valid between the scaled input lower & upper limits
(applies if Pre-Tune Type = Pre-tune at Value)
Hex 112F 512F A25E
Loop 1 Pretune Set Value PID Set Pre-tune Will Optimize
Dec 4397 20781 41562
RW
0 PID Set 1
Hex 112D 512D A25A
1 PID Set 2
2 PID Set 3
3 PID Set 4
4 PID Set 5
Loop 1 Pretune Cascade Loop Value Cascade Loop To Be Pre-Tuned
Dec 4398 20782 41564
RW
0
Slave (opens cascade - close when finished)
Hex 112E 512E A25C
1
Master (tunes master/slave combination)
Loop 1 Pre-Tune Engage/disengage Value Pre-Tune Engage/Disengage For Loop 1
Dec 4325 20709 41418
RW
0 Pre-Tune OFF
Hex 10E5 50E5 A1CA
1 Run Pre-Tune
Loop 1 Self-Tune Engage/disengage Value Self-Tune Engage/Disengage For Loop 1
Dec 4326 20710 41420
RW
0 Self-Tune OFF
Hex 10E6 50E6 A1CC
1 Self-Tune ON
Loop 1 Loop Alarm Type Value Loop Alarm Type For Loop 1
Dec 4327 20711 41422
RW
1 User Defined Time
Hex 10E7 50E7 A1CE
2
Automatic (2x Integral Time)
Loop Alarm Time Loop Alarm Activation Time
Dec 4328 20712 41424
RW
1 to 5999 Seconds after output loop 1 power reaches saturation
Hex 10E8 50E8 A1D0
Loop 1 Primary Power Loop 1 Primary Power Level
Dec 4329 20713 41426
RO
The current loop 1 primary power level (0 to 100%)
Hex 10E9 50E9 A1D2
Loop 1 Secondary Power Loop 1 Secondary Power Level
Dec 4330 20714 41428
RO
The current loop 1 secondary power level (0 to 100%)
Hex 10EA 50EA A1D4
