Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 154
Loop 1 Combined Power Loop 1 Combined Primary & Secondary Power Level
Dec 4331 20715 41430
RO
The current loop 1 combined PID power level (-100 to 100%)
Hex 10EB 50EB A1D6
Loop 1 Pre-Tune Status Value Pre-Tune Status For Loop 1
Dec 4332 20716 41432
RO
0 Inactive
Hex 10EC 50EC A1D8
1 Active
Loop 1 Self-Tune Status Value Self-Tune Status For Loop 1
Dec 4333 20717 41434
RO
0 Inactive
Hex 10ED 50ED A1DA
1 Active
Loop 1 Loop Alarm status Value Loop Alarm Status For Loop 1
Dec 4334 20718 41436
RO
0 Inactive
Hex 10EE 50EE A1DC
1 Active
Loop 1 Input Failure Pre-set Power Loop 1 Input Sensor Break Pre-set Power
Dec 4335 20719 41438
RW
The pre-defined power output applied if input signal is lost
0 to 100% (-100% to 100% for dual control).
Hex 10EF 50EF A1DE
Loop 1 Auto Pre-tune Value Auto Pre-Tune At Every Power-up For Loop 1
Dec 4336 20720 41440
RW
0 Disabled
Hex 10F0 50F0 A1E0
1 Enabled
Pre-tune Secondary Status Value Pre-tune Secondary Status
Dec 4341 20725 41450
RO
0 No Additional Information
Hex 10F5 50F5 A1EA
1
PV within 5% (Pre-Tune cannot run)
2
Manual Control Enabled (Pre-Tune cannot run)
3
Control has On/Off element (Pre-Tune cannot run)
4
Input not valid (Pre-Tune cannot run)
5
Control Disabled (Pre-Tune cannot run)
6
Profile Running (Pre-Tune cannot run)
7
Setpoint Ramping (Pre-Tune cannot run)
Self-tune Secondary Status Value Self-tune Secondary Status
Dec 4342 20726 41452
RO
0 No Additional Information
Hex 10F6 50F6 A1EC
2
Manual Control Enabled (Self-Tune cannot run)
3
Control has On/Off element (Self-Tune cannot run)
4
Input not valid (Self-Tune cannot run)
5
Control Disabled (Self-Tune cannot run)
Loop 1 Anti Wind-up Limit Loop 1 Anti Wind-up Limit
Dec 4391 20775 41550
RW
Power level where integral action is suspended.
Adjustable from 10.0 to 100.0% of PID power.
Hex 1127 5127 A24E
Loop 1 Motor Travel Time Loop 1 Motor Travel Time
Dec 4343 20727 41454
RW
The motor travel time (from fully open to fully closed) for 3-point
stepping VMD control. Adjustable from 5 to 300 seconds.
Hex 10F7 50F7 A1EE
Loop 1 Minimum Motor On Time Loop 1 Minimum Motor On Time
Dec 4344 20728 41456
RW
Minimum drive effort to begin moving valve for 3-point stepping
VMD control. In seconds, from 0.02 to 1/10 of Motor Travel Time
Hex 10F8 50F8 A1F0
Loop 1 VMD Break Action Value Loop 1 Sensor Break Action For VMD Control
Dec 4401 20785 41570
RW
0 Close Valve Output On
Hex 1131 5131 A262
1 Open Valve Output On
Loop 1 Valve Close Limit Loop 1 Minimum Valve Position
Dec 4376 20760 41520
RW
Minimum position to drive valve in VMD Mode
from the valve close limit+1% to 100.0%
Hex 1118 5118 A230
