Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 155
Loop 1 Valve Open Limit Loop 1 Maximum Valve Position
Dec 4377 20761 41522
RW
Maximum position to drive valve in VMD Mode.
From 0.0% to the valve open limit-1%
Hex 1119 5119 A232
Loop 1 PID Set Select Value Loop 1 PID Set Selection
Dec 4367 20751 41502
RW
0 PID Set 1
Hex 110F 510F A21E
1 Gain Schedule Selected by SP
2 Gain Schedule Selected by PV
3 PID Set 2
4 PID Set 3
5 PID Set 4
6 PID Set 5
PID Set 2 - Primary Prop Band PID Set 2 Primary Proportional Band For Loop 1
Dec 4347 20731 41462
RW
Primary Proportional Band for Gain Set 2.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 10FB 50FB A1F6
PID Set 2 - Secondary Prop Band PID Set 2 Secondary Proportional Band For Loop1
Dec 4348 20732 41464
RW
Secondary Proportional Band for Gain Set 2.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 10FC 50FC A1F8
PID Set 2 - Integral Time PID Set 2 - Integral Time For Loop 1
Dec 4349 20733 41466
RW
Gain Set 2 integral time constant for loop 1
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 10FD 50FD A1FA
PID Set 2 - Derivative Time PID Set 2 - Derivative Time For Loop 1
Dec 4350 20734 41468
RW
Gain Set 2 derivative time constant for loop 1
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 10FE 50FE A1FC
PID Set 2 - Overlap/Deadband PID Set 2 - Overlap/Deadband For Loop 1
Dec 4351 20735 41470
RW
PID Set 2 overlap (+ve) or deadband (-ve) between primary &
secondary prop bands. In display units - limited to 20% of the
combined band width.
Hex 10FF 50FF A1FE
PID Set 2 - On/Off Differential PID Set 2 - On/Off Differential For Loop 1
Dec 4378 20762 41524
RW
The on-off control hysteresis (deadband) for PID Set 2.
1 to 300 display units, centred about the setpoint.
Hex 111A 511A A234
PID Set 3 - Primary Prop Band PID Set 3 Primary Proportional Band For Loop 1
Dec 4352 20736 41472
RW
Primary Proportional Band for Gain Set 3.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 1100 5100 A200
PID Set 3 - Secondary Prop Band PID Set 3 Secondary Proportional Band For Loop 1
Dec 4353 20737 41474
RW
Secondary Proportional Band for Gain Set 3.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 1101 5101 A202
PID Set 3 - Integral Time PID Set 3 - Integral Time For Loop 1
Dec 4354 20738 41476
RW
Gain Set 3 integral time constant for loop 1
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 1102 5102 A204
PID Set 3 - Derivative Time PID Set 3 - Derivative Time For Loop 1
Dec 4355 20739 41478
RW
Gain Set 3 derivative time constant for loop 1
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 1103 5103 A206
PID Set 3 - Overlap/Deadband PID Set 3 - Overlap/Deadband For Loop 1
Dec 4356 20740 41480
RW
PID Set 3 overlap (+ve) or deadband (-ve) between primary &
secondary prop bands. In display units - limited to 20% of the
combined band width.
Hex 1104 5104 A208
