PID Set 3 - On/Off Differential PID Set 3 - On/Off Differential For Loop 1
Dec 4379 20763 41526
RW
The on-off control hysteresis (deadband) for PID Set 3.
1 to 300 display units, centred about the setpoint.
Hex 111B 511B A236
PID Set 4 - Primary Prop Band PID Set 4 Primary Proportional Band For Loop 1
Dec 4357 20741 41482
RW
Primary Proportional Band for Gain Set 4.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 1105 5105 A20A
PID Set 4 - Secondary Prop Band PID Set 4 Secondary Proportional Band For Loop 1
Dec 4358 20742 41484
RW
Secondary Proportional Band for Gain Set 4.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 1106 5106 A20C
PID Set 4 - Integral Time PID Set 4 - Integral Time For Loop 1
Dec 4359 20743 41486
RW
Gain Set 4 integral time constant for loop 1
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 1107 5107 A20E
PID Set 4 - Derivative Time PID Set 4 - Derivative Time For Loop 1
Dec 4360 20744 41488
RW
Gain Set 4 derivative time constant for loop 1
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 1108 5108 A210
PID Set 4 - Overlap/Deadband PID Set 4 - Overlap/Deadband For Loop 1
Dec 4361 20745 41490
RW
PID Set 4 overlap (+ve) or deadband (-ve) between primary &
secondary prop bands. In display units - limited to 20% of the
combined band width.
Hex 1109 5109 A212
PID Set 4 - On/Off Differential PID Set 4 - On/Off Differential For Loop 1
Dec 4380 20764 41528
RW
The on-off control hysteresis (deadband) for PID Set 4.
1 to 300 display units, centred about the setpoint.
Hex 111C 511C A238
PID Set 5 - Primary Prop Band PID Set 5 Primary Proportional Band For Loop 1
Dec 4362 20746 41492
RW
Primary Proportional Band for Gain Set 5.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 110A 510A A214
PID Set 5 - Secondary Prop Band PID Set 5 Secondary Proportional Band For Loop 1
Dec 4363 20747 41494
RW
Secondary Proportional Band for Gain Set 5.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 110B 510B A216
PID Set 5 - Integral Time PID Set 5 - Integral Time For Loop 1
Dec 4364 20748 41496
RW
Gain Set 5 integral time constant for loop 1
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 110C 510C A218
PID Set 5 - Derivative Time PID Set 5 - Derivative Time For Loop 1
Dec 4365 20749 41498
RW
Gain Set 5 derivative time constant for loop 1
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 110D 510D A21A
PID Set 5 - Overlap/Deadband PID Set 5 - Overlap/Deadband For Loop 1
Dec 4366 20750 41500
RW
PID Set 5 overlap (+ve) or deadband (-ve) between primary &
secondary prop bands. In display units - limited to 20% of the
combined band width.
Hex 110E 510E A21C
PID Set 5 - Overlap/Deadband PID Set 5 - On/Off Differential For Loop 1
Dec 4381 20765 41530
RW
The on-off control hysteresis (deadband) for PID Set 5.
1 to 300 display units, centred about the setpoint.
Hex 111D 511D A23A
Loop 1 Gain Set 2 Breakpoint Gain Scheduling PID Set 1 To 2 Switch Point
Dec 4369 20753 41506
RW
Value (SP or PV) gain scheduling switches from PID Set 1 To 2.
Value between Scaled Input 1 Lower & Upper Limits
Hex 1111 5111 A222
Loop 1 Gain Set 3 Breakpoint Gain Scheduling PID Set 2 To 3 Switch Point
Dec 4370 20754 41508
RW
Value (SP or PV) gain scheduling switches from PID Set 2 To 3.
Value between Set 2 Breakpoint & Scaled Input 1 Upper Limit.
Hex 1112 5112 A224
