Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 157
Loop 1 Gain Set 4 Breakpoint Gain Scheduling PID Set 3 To 4 Switch Point
Dec 4371 20755 41510
RW
Value (SP or PV) gain scheduling switches from PID Set 3 To 4.
Value between Set 3 Breakpoint & Scaled Input 1 Upper Limit.
Hex 1113 5113 A226
Loop 1 Gain Set 5 Breakpoint Gain Scheduling PID Set 4 To 5 Switch Point
Dec 4372 20756 41512
RW
Value (SP or PV) gain scheduling switches from PID Set 4 To 5.
Value between Set 4 Breakpoint & Scaled Input 1 Upper Limit.
Hex 1114 5114 A228
Loop 1 Cascade Mode Value Cascade Master/Slave Link Status
Dec 4393 20777 41554
RW
0 Cascade Closed
Hex 1129 5129 A252
1 Cascade Open
Loop 1 Ratio NO Constant Ratio NO Constant For Atomizing Air
Dec 4387 20771 41542
RW
0 to 9999 atomizing air value,
Added to the x1 value in ratio mode (air flow is x1 + NO).
Hex 1123 5123 A246
Loop 1 Ratio Sfac Constant Ratio Sfac Constant
Dec 4388 20772 41544
RW
Ratio control mode scaling factor. Adjustable from 0.010 to
99.999
Hex 1124 5124 A248
Loop 2 Control Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Loop 2 Manual Control Select Value Selection
Dec 4408 20792 41584
RW
0 Automatic Mode
Hex 1138 5138 A270
1 Manual Mode
Loop 2 Control Enable Select Value Control Enable Selection
Dec 4409 20793 41586
RW
0 Disabled
Hex 1139 5139 A272
1 Enabled
Loop 2 Auto/Manual Access Value Operator Access To Auto/Manual Control
Dec 4494 20878 41756
RW
0 Off
Hex 118E 518E A31C
1 On
Loop 2 Control Enable Access Value Operator Access To Control Enable/Disable
Dec 4495 20879 41758
RW
0 Off
Hex 118F 518F A31E
1 On
Loop 2 Primary Cycle Time Cycle Time For Primary Control Outputs
Dec 4303 20687 41374
RW
0.5 to 512.0 Seconds
Hex 10CF 50CF A19E
Loop 2 Secondary Cycle Time Cycle Time For Secondary Control Outputs
Dec 4304 20688 41376
RW
0.5 to 512.0 Seconds
Hex 10D0 50D0 A1A0
Loop 2 Control Selection Value Control Actuator Type Selection
Dec 4407 20791 41582
RW
0
Standard (Time Proportioned or Continuous PID)
Hex 1137 5137 A26E
1
VMD (3-Point Stepping for Valve Motor Drive)
Loop 2 Control type Value Primary Only or Primary & Secondary
Dec 4410 20794 41588
RW
0
Single (Primary Only Control)
Hex 113A 513A A274
1
Dual Control (Primary & Secondary Control)
