Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 159
Loop 2 Pre-Tune Set Value PID Set Pre-tune Will Optimize
Dec 4497 20881 41762
RW
0 PID Set 1
Hex 1191 5191 A322
1 PID Set 2
2 PID Set 3
3 PID Set 4
4 PID Set 5
Loop 2 Pre-Tune Engage/disengage Value Pre-Tune Engage/disengage For Loop 2
Dec 4425 20809 41618
RW
0 Pre-Tune OFF
Hex 1149 5149 A292
1 Run Pre-Tune
Loop 2 Self-Tune Engage/disengage Value Self-Tune Engage/disengage For Loop 2
Dec 4426 20810 41620
RW
0 Self-Tune OFF
Hex 114A 514A A294
1 Self-Tune ON
Loop 2 Loop Alarm Type Value Loop Alarm Type For Loop 2
Dec 4427 20811 41622
RW
1 User Defined Time
Hex 114B 514B A296
2
Automatic (2x Integral Time)
Loop Alarm Time Loop Alarm Activation Time
Dec 4428 20812 41624
RW
1 to 5999 Seconds after output loop 2 power reaches saturation
Hex 114C 514C A298
Loop 2 Primary Power Loop 2 Primary Power Level
Dec 4429 20813 41626
RO
The current loop 2 primary power level (0 to 100%)
Hex 114D 514D A29A
Loop 2 Secondary Power Loop 2 Secondary Power Level
Dec 4430 20814 41628
RO
The current loop 2 secondary power level (0 to 100%)
Hex 114E 514E A29C
Loop 2 Combined Power Loop 2 Combined Primary & Secondary Power Level
Dec 4431 20815 41630
RO
The current loop 2 combined PID power level (-100 to 100%)
Hex 114F 514F A29E
Loop 2 Pre-Tune Status Value Pre-Tune Status For Loop 2
Dec 4432 20816 41632
RO
0 Inactive
Hex 1150 5150 A2A0
1 Active
Loop 2 Self-Tune Status Value Self-Tune Status For Loop 2
Dec 4433 20817 41634
RO
0 Inactive
Hex 1151 5151 A2A2
1 Active
Loop 2 Loop Alarm status Value Loop Alarm Status For Loop 2
Dec 4434 20818 41636
RO
0 Inactive
Hex 1152 5152 A2A4
1 Active
Loop 2 Input Failure Pre-set Power Loop 2 Input Sensor Break Pre-set Power
Dec 4435 20819 41638
RW
The pre-defined power output applied if input signal is lost
0 to 100% (-100% to 100% for dual control).
Hex 1153 5153 A2A6
Loop 2 Auto Pre-tune Value Auto Pre-Tune At Every Power-up For Loop 2
Dec 4436 20820 41640
RW
0 Disabled
Hex 1154 5154 A2A8
1 Enabled
