Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 160
Pre-Tune Secondary Status Value Loop 2 Pre-Tune Secondary Status
Dec 4441 20825 41650
RW
0 No Additional Information
Hex 1159 5159 A2B2
1
PV within 5% (Pre-Tune cannot run)
2
Manual Control Enabled (Pre-Tune cannot run)
3
Control has On/Off element (Pre-Tune cannot run)
4
Input not valid (Pre-Tune cannot run)
5
Control Disabled (Pre-Tune cannot run)
6
Profile Running (Pre-Tune cannot run)
7
Setpoint Ramping (Pre-Tune cannot run)
Self-Tune Secondary Status Value Loop 2 Self-Tune Secondary Status
Dec 4442 20826 41652
RW
0 No Additional Information
Hex 115A 515A A2B4
2
Manual Control Enabled (Self-Tune cannot run)
3
Control has On/Off element (Self-Tune cannot run)
4
Input not valid (Self-Tune cannot run)
5
Control Disabled (Self-Tune cannot run)
Loop 2 Anti Wind-up Limit Loop 2 Anti Wind-up Limit
Dec 4491 20875 41750
RW
Power level where integral action is suspended.
Adjustable from 10.0 to 100.0% of PID power.
Hex 118B 518B A316
Loop 2 Motor Travel Time Loop 2 Motor Travel Time
Dec 4443 20827 41654
RW
The motor travel time (from fully open to fully closed) for 3-point
stepping VMD control. Adjustable from 5 to 300 seconds.
Hex 115B 515B A2B6
Loop 2 Minimum Motor On Time Loop 2 Minimum Motor On Time
Dec 4444 20828 41656
RW
Minimum drive effort to begin moving valve for 3-point stepping
VMD control. In seconds, from 0.02 to 1/10 of Motor Travel Time
Hex 115C 515C A2B8
Loop 2 Valve Break Action Value Loop 2 Sensor Break Action For VMD Control
Dec 4501 20885 41770
RW
0 Close Valve Output On
Hex 1195 5195 A32A
1 Open Valve Output On
Loop 2 Minimum Valve Position Loop 2 Minimum Valve Position
Dec 4476 20860 41720
RW
Minimum position to drive valve in VMD Mode
from the valve close limit+1% to 100.0%
Hex 117C 517C A2F8
Loop 2 Maximum Valve Position Loop 2 Maximum Valve Position
Dec 4477 20861 41722
RW
Maximum position to drive valve in VMD Mode.
From 0.0% to the valve open limit-1%
Hex 117D 517D A2FA
Loop 2 PID Set Select Value Loop 2 PID Set Selection
Dec 4467 20851 41702
RW
0 PID Set 1
Hex 1173 5173 A2E6
1 Gain Schedule Selected by SP
2 Gain Schedule Selected by PV
3 PID Set 2
4 PID Set 3
5 PID Set 4
6 PID Set 5
PID Set 2 - Primary Prop Band PID Set 2 Primary Proportional Band For Loop 2
Dec 4447 20831 41662
RW
Primary Proportional Band for Gain Set 2.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 115F 515F A2BE
PID Set 2 - Secondary Prop Band PID Set 2 Secondary Proportional Band For Loop1
Dec 4448 20832 41664
RW
Secondary Proportional Band for Gain Set 2.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 1160 5160 A2C0
