PID Set 2 - Integral Time PID Set 2 - Integral Time For Loop 2
Dec 4449 20833 41666
RW
Gain Set 2 integral time constant for Loop 2
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 1161 5161 A2C2
PID Set 2 - Derivative Time PID Set 2 - Derivative Time For Loop 2
Dec 4450 20834 41668
RW
Gain Set 2 derivative time constant for Loop 2
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 1162 5162 A2C4
PID Set 2 - Overlap/Deadband PID Set 2 - Overlap/Deadband For Loop 2
Dec 4451 20835 41670
RW
PID Set 2 overlap (+ve) or deadband (-ve) between primary &
secondary prop bands. In display units - limited to 20% of the
combined band width.
Hex 1163 5163 A2C6
PID Set 2 - On/Off Differential PID Set 2 - On/Off Differential For Loop 2
Dec 4478 20862 41724
RW
The on-off control hysteresis (deadband) for PID Set 2.
1 to 300 display units, centred about the setpoint.
Hex 117E 517E A2FC
PID Set 3 - Primary Prop Band PID Set 3 Primary Proportional Band For Loop 2
Dec 4452 20836 41672
RW
Primary Proportional Band for Gain Set 3.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 1164 5164 A2C8
PID Set 3 - Secondary Prop Band PID Set 3 Secondary Proportional Band For Loop 2
Dec 4453 20837 41674
RW
Secondary Proportional Band for Gain Set 3.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 1165 5165 A2CA
PID Set 3 - Integral Time PID Set 3 - Integral Time For Loop 2
Dec 4454 20838 41676
RW
Gain Set 3 integral time constant for Loop 2
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 1166 5166 A2CC
PID Set 3 - Derivative Time PID Set 3 - Derivative Time For Loop 2
Dec 4455 20839 41678
RW
Gain Set 3 derivative time constant for Loop 2
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 1167 5167 A2CE
PID Set 3 - Overlap/Deadband PID Set 3 - Overlap/Deadband For Loop 2
Dec 4456 20840 41680
RW
PID Set 3 overlap (+ve) or deadband (-ve) between primary &
secondary prop bands. In display units - limited to 20% of the
combined band width.
Hex 1168 5168 A2D0
PID Set 3 - On/Off Differential PID Set 3 - On/Off Differential For Loop 2
Dec 4479 20863 41726
RW
The on-off control hysteresis (deadband) for PID Set 3.
1 to 300 display units, centred about the setpoint.
Hex 117F 517F A2FE
PID Set 4 - Primary Prop Band PID Set 4 Primary Proportional Band For Loop 2
Dec 4457 20841 41682
RW
Primary Proportional Band for Gain Set 4.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 1169 5169 A2D2
PID Set 4 - Secondary Prop Band PID Set 4 Secondary Proportional Band For Loop 2
Dec 4458 20842 41684
RW
Secondary Proportional Band for Gain Set 4.
1 display unit to 9999 units,
but limited to 10 x scaled input span. 0 = On-Off control
Hex 116A 516A A2D4
PID Set 4 - Integral Time PID Set 4 - Integral Time For Loop 2
Dec 4459 20843 41686
RW
Gain Set 4 integral time constant for Loop 2
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 116B 516B A2D6
PID Set 4 - Derivative Time PID Set 4 - Derivative Time For Loop 2
Dec 4460 20844 41688
RW
Gain Set 4 derivative time constant for Loop 2
0.1 to 5999 Seconds. 0 or 6000 = OFF
Hex 116C 516C A2D8
