West Control Solutions Pro-EC44 - Page 173

Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 167
Alarm 4 Type Value Alarm 4 Type
Dec 6192 22576 45152
RW
0 Unused
Hex 1830 5830 B060
1 Process High Alarm
2 Process Low Alarm
3 Deviation Alarm (SP-PV)
4 Band Alarm
5 Input Rate of Change
6 Input/Sensor Break Alarm
7 Loop Alarm
10 % memory used
11 High Power Alarm
12 Low Power Alarm
Alarm 4 Value Value At Which Alarm 4 Activates
Dec 6193 22577 45154
RW
Limited by input scaling for alarm types 1 to 4.
Not used for alarms 5, 6 or 7.
0 to 100% for alarms 10 to 12.
Hex 1831 5831 B062
Alarm 4 Rate of Change Value Process Variable Rate of Change Alarm Threshold
Dec 6198 22582 45164
RW
Value for Rate of Change Alarm. Alarm 4 activates when PV
change exceeds this level. From 0.0 to 99999
Hex 1836 5836 B06C
Alarm 4 Hysteresis Alarm 4 Hysteresis Value
Dec 6194 22578 45156
RW
Deadband value (on “safe” side of alarm), through which signal
must pass before Alarm 4 deactivates.
Limited by the input scaling span
Hex 1832 5832 B064
Alarm 4 Inhibit Enable/disable Value Alarm 4 Power-up/Setpoint Change Inhibit
Dec 6195 22579 45158
RW
0 Disabled
Hex 1833 5833 B066
1 Enabled
Alarm 4 Status Value Alarm 4 Status
Dec 6196 22580 45160
RO
0 Inactive
Hex 1834 5834 B068
1 Active
Alarm 4 Inhibit Status Value Alarm 4 Inhibit Status
Dec 6197 22581 45162
RO
0 Not Inhibited
Hex 1835 5835 B06A
1 Inhibited
Alarm 4 Label Main Language Name For Alarm 4 In Status Screen
Dec 6199 22583 45166
RW
8 ASCII characters replacing the title "Alarm 4" in alarm status
screens when main display language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1837 5837 B06E
Alarm 4 Alternate Label Alternate Language Name For Alarm 4 In Status Screen
Dec 6200 22584 45168
RW
8 ASCII characters replacing the title "Alarm 4" in alarm status
screens when the alternate language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1838 5838 B070
Alarm 4 Minimum Duration Alarm 4 Minimum Duration
Dec 6201 22585 45170
RW
Minimum time alarm 4 must be passed its threshold before
activating (deactivation is not affected by this parameter).
From 0 to 9999 secs
Hex 1839 5839 B072
