Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 172
Memory Remaining Remaining Data Recorder Capacity
Dec 7554 23938 47876
RO
The unused memory remaining, in bytes.
Hex 1D82 5D82 BB04
Time Remaining Remaining Data Recorder Time
Dec 7555 23939 47878
RO
Approximate recording time remaining until memory filled, in
seconds. Based on the current recorder settings & sample rate.
Hex 1D83 5D83 BB06
Recorder Auto-Alarm Trigger Value Automatic Data Recorder Trigger
Dec 7563 23947 47894
RW
0 None
Hex 1D8B 5D8B BB16
1 On Alarm
2 On Profile Run
3 On Alarm or Profile Running
Operator Access To Record Trigger Value Operator Access To Manual Record Trigger
Dec 7559 23943 47886
RW
0 No
Hex 1D87 5D87 BB0E
1 Yes
Recorder Status In Operator Mode Value Recorder Status Visible In Operator Mode
Dec 7560 23944 47888
RW
0 No
Hex 1D88 5D88 BB10
1 Yes
Record Input 1 Process Variable Value Record Process Variable Of Input 1
Dec 7572 23956 47912
RW
0 Do Not Record PV
Hex 1D94 5D94 BB28
1 Record PV Value
Record Input 1 Max Between Samples Value Record Max PV For Input 1 Since Last Sample
Dec 7573 23957 47914
RW
0 Do Not Record Maximum PV
Hex 1D95 5D95 BB2A
1 Record Maximum PV Between Samples
Record Input 1 Min Between Samples Value Record Min PV For Input 1 Since Last Sample
Dec 7574 23958 47916
RW
0 Do Not Record Minimum PV
Hex 1D96 5D96 BB2C
1 Record Minimum PV Between Samples
Record Input 2 Process Variable Value Record Process Variable Of Input 2
Dec 7607 23991 47982
RW
0 Do Not Record PV
Hex 1DB7 5DB7 BB6E
1 Record PV Value
Record Input 2 Max Between Samples Value Record Max PV For Input 2 Since Last Sample
Dec 7608 23992 47984
RW
0 Do Not Record Maximum PV
Hex 1DB8 5DB8 BB70
1 Record Maximum PV Between Samples
Record Input 2 Min Between Samples Value Record Min PV For Input 2 Since Last Sample
Dec 7609 23993 47986
RW
0 Do Not Record Minimum PV
Hex 1DB9 5DB9 BB72
1 Record Minimum PV Between Samples
Record Aux A Input Value Record Auxiliary A Input Value
Dec 7606 23990 47980
RW
0 Do Not Record Aux A
Hex 1DB6 5DB6 BB6C
1 Record Aux A Value
Record Loop 1 Actual Setpoint Value Record Effective Value of Loop 1 Setpoint
Dec 7575 23959 47918
RW
0 Do Not Record Setpoint
Hex 1D97 5D97 BB2E
1 Record Actual Setpoint
Record Loop 2 Actual Setpoint Value Record Effective Value of Loop 2 Setpoint
Dec 7610 23994 47988
RW
0 Do Not Record Setpoint
Hex 1DBA 5DBA BB74
1 Record Actual Setpoint
