Pro-EC44 Product Manual - 59540-2 September 2014 Page 171
Alarm 7 Inhibit Enable/disable Value Alarm 7 Power-up/Setpoint Change Inhibit
Dec 6243 22627 45254
RW
0 Disabled
Hex 1863 5863 B0C6
1 Enabled
Alarm 7 Status Value Alarm 7 Status
Dec 6244 22628 45256
RO
0 Inactive
Hex 1864 5864 B0C8
1 Active
Alarm 7 Inhibit Status Value Alarm 7 Inhibit Status
Dec 6245 22629 45258
RO
0 Not Inhibited
Hex 1865 5865 B0CA
1 Inhibited
Alarm 7 Label Main Language Name For Alarm 7 In Status Screen
Dec 6247 22631 45262
RW
8 ASCII characters replacing the title "Alarm 7" in alarm status
screens when main display language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1867 5867 B0CE
Alarm 7 Alternate Label Alternate Language Name For Alarm 7 In Status Screen
Dec 6248 22632 45264
RW
8 ASCII characters replacing the title "Alarm 7" in alarm status
screens when the alternate language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1868 5868 B0D0
Alarm 7 Minimum Duration Alarm 7 Minimum Duration
Dec 6249 22633 45266
RW
Minimum time alarm 7 must be passed its threshold before
activating (deactivation is not affected by this parameter).
From 0 to 9999 secs
Hex 1869 5869 B0D2
Recorder & Clock Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Recording Sample Interval Value Recording Sample Interval
Dec 7550 23934 47868
RW
0 Every Second
Hex 1D7E 5D7E BAFC
1 Every 2 Seconds
2 Every 5 Seconds
3 Every 10 Seconds
4 Every 15 Seconds
5 Every 30 Seconds
6 Every Minute
7 Every 2 Minutes
8 Every 5 Minutes
9 Every 10 Minutes
10 Every 15 Minutes
11 Every 30 Minutes
Recording Mode Value Recording Mode
Dec 7551 23935 47870
RW
0 Record until memory used
Hex 1D7F 5D7F BAFE
1 Continuous FIFO buffer
Manual Recording Trigger Value Manual Recording Trigger
Dec 7552 23936 47872
RW
0 Manual Recording Trigger Off
Hex 1D80 5D80 BB00
1 Manual Recording Trigger On
Data Recorder Fitted Value Data Recorder Fitted
Dec 7553 23937 47874
RO
0 Not Fitted
Hex 1D81 5D81 BB02
1 Recorder Fitted
