Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 170
Alarm 6 Inhibit Status Value Alarm 6 Inhibit Status
Dec 6229 22613 45226
RO
0 Not Inhibited
Hex 1855 5855 B0AA
1 Inhibited
Alarm 6 Label Main Language Name For Alarm 6 In Status Screen
Dec 6231 22615 45230
RW
8 ASCII characters replacing the title "Alarm 6" in alarm status
screens when main display language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1857 5857 B0AE
Alarm 6 Alternate Label Alternate Language Name For Alarm 6 In Status Screen
Dec 6232 22616 45232
RW
8 ASCII characters replacing the title "Alarm 6" in alarm status
screens when the alternate language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1858 5858 B0B0
Alarm 6 Minimum Duration Alarm 6 Minimum Duration
Dec 6233 22617 45234
RW
Minimum time alarm 6 must be passed its threshold before
activating (deactivation is not affected by this parameter).
From 0 to 9999 secs
Hex 1859 5859 B0B2
Alarm 7 Input Source Value Source
Dec 6239 22623 45246
RW
0 Input 1
Hex 185F 585F B0BE
1 Input 2
2 Aux A Input
3 Control Loop 1 Primary Power
4 Control Loop 1 Secondary Power
5 Control Loop 2 Primary Power
6 Control Loop 2 Secondary Power
7 Loop 1
8 Loop 2
Alarm 7 Type Value Alarm 7 Type
Dec 6240 22624 45248
RW
0 Unused
Hex 1860 5860 B0C0
1 Process High Alarm
2 Process Low Alarm
3 Deviation Alarm (SP-PV)
4 Band Alarm
5 Input Rate of Change
6 Input/Sensor Break Alarm
7 Loop Alarm
10 % memory used
11 High Power Alarm
12 Low Power Alarm
Alarm 7 Value Value At Which Alarm 7 Activates
Dec 6241 22625 45250
RW
Limited by input scaling for alarm types 1 to 4.
Not used for alarms 5, 6 or 7.
0 to 100% for alarms 10 to 12.
Hex 1861 5861 B0C2
Alarm 7 Rate of Change Value Process Variable Rate of Change Alarm Threshold
Dec 6246 22630 45260
RW
Value for Rate of Change Alarm. Alarm 7 activates when PV
change exceeds this level. From 0.0 to 99999
Hex 1866 5866 B0CC
Alarm 7 Hysteresis Alarm 7 Hysteresis Value
Dec 6242 22626 45252
RW
Deadband value (on “safe” side of alarm), through which signal
must pass before Alarm 7 deactivates.
Limited by the input scaling span
Hex 1862 5862 B0C4
