Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 169
Alarm 5 Alternate Label Alternate Language Name For Alarm 5 In Status Screen
Dec 6216 22600 45200
RW
8 ASCII characters replacing the title "Alarm 5" in alarm status
screens when the alternate language is used, read/written with
Modbus functions 16 or 23. Valid characters are 0 to 9, a to z, A
to Z, plus ß ö ( ) - and _.
Hex 1848 5848 B090
Alarm 5 Minimum Duration Alarm 5 Minimum Duration
Dec 6217 22601 45202
RW
Minimum time alarm 5 must be passed its threshold before
activating (deactivation is not affected by this parameter).
From 0 to 9999 secs
Hex 1849 5849 B092
Alarm 6 Input Source Value Source
Dec 6223 22607 45214
RW
0 Input 1
Hex 184F 584F B09E
1 Input 2
2 Aux A Input
3 Control Loop 1 Primary Power
4 Control Loop 1 Secondary Power
5 Control Loop 2 Primary Power
6 Control Loop 2 Secondary Power
7 Loop 1
8 Loop 2
Alarm 5 Type Value Alarm 5 Type
Dec 6224 22608 45216
RW
0 Unused
Hex 1850 5850 B0A0
1 Process High Alarm
2 Process Low Alarm
3 Deviation Alarm (SP-PV)
4 Band Alarm
5 Input Rate of Change
6 Input/Sensor Break Alarm
7 Loop Alarm
10 % memory used
11 High Power Alarm
12 Low Power Alarm
Alarm 6 Value Value At Which Alarm 6 Activates
Dec 6225 22609 45218
RW
Limited by input scaling for alarm types 1 to 4.
Not used for alarms 5, 6 or 7.
0 to 100% for alarms 10 to 12.
Hex 1851 5851 B0A2
Alarm 6 Rate of Change Value Process Variable Rate of Change Alarm Threshold
Dec 6230 22614 45228
RW
Value for Rate of Change Alarm. Alarm 6 activates when PV
change exceeds this level. From 0.0 to 99999
Hex 1856 5856 B0AC
Alarm 6 Hysteresis Alarm 6 Hysteresis Value
Dec 6226 22610 45220
RW
Deadband value (on “safe” side of alarm), through which signal
must pass before Alarm 6 deactivates.
Limited by the input scaling span
Hex 1852 5852 B0A4
Alarm 6 Inhibit Enable/disable Value Alarm 6 Power-up/Setpoint Change Inhibit
Dec 6227 22611 45222
RW
0 Disabled
Hex 1853 5853 B0A6
1 Enabled
Alarm 6 Status Value Alarm 6 Status
Dec 6228 22612 45224
RO
0 Inactive
Hex 1854 5854 B0A8
1 Active
