Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 177
LED 1 Usage Value LED 1 Usage. For 8 & 9 see also LED 1 Selections.
Dec 7664 24048 48096
RW
0 Loop 1 Primary Control ON = LED 1 ON
Hex 1DF0 5DF0 BBE0
1 Loop 1 Secondary Control ON = LED 1 ON
2 Loop 2 Primary Control ON = LED 1 ON
3 Loop 2 Secondary Control ON = LED 1 ON
4 Loop 1 VMD Open ON = LED 1 ON
5 Loop 1 VMD Close ON = LED 1 ON
6 Loop 2 VMD Open ON = LED 1 ON
7 Loop 2 VMD Close ON = LED 1 ON
8
Alarm/Event/Digital/Control (Logical OR)
9
Alarm/Event/Digital/Control inverted (Logical NOR)
Value 8 (Logical OR selection of Alarm/Events/Digital/Control) turns ON the LED if any of the selected
alarms, events, inputs or functions are active.
Value 9 (Logical NOR selection of Alarm/Events/Digital/Control) turns OFF the LED if any of the selected
alarms, events, inputs or functions are active.
Note: Pre-tune will flash the LED instead of turning it on, but flashing will be obscured if used in
conjunction with other functions when they are on.
LED 1 Alarm Indication Bit If bit =1, Alarm n status is selected
Dec 7690 24074 48148
RW
0 Alarm 1
Hex 1E0A 5E0A BC14
1 Alarm 2
2 Alarm 3
3 Alarm 4
4 Alarm 5
5 Alarm 6
6 Alarm 7
LED 1 Profiler Event Indication Bit If bit =1, Event n status is selected
Dec 7692 24076 48152
RW
0 Event 1
Hex 1E0C 5E0C BC18
1 Event 2
2 Event 3
3 Event 4
4 Event 5
5 Profile Running
6 Profile End
LED 1 Slot A & Soft Input Indication Bit If bit =1, Digital A / Soft Input n status is selected
Dec 7694 24078 48156
RW
0 Digital Input A
Hex 1E0E 5E0E BC1C
1 Soft Digital 1
2 Soft Digital 2
3 Soft Digital 3
4 Soft Digital 4
