Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 178
LED 1 Option C Digital Indication Bit If bit =1, Digital Cn status is selected
Dec 7696 24080 48160
RW
0 Digital Input C1
Hex 1E10 5E10 BC20
1 Digital Input C2
2 Digital Input C3
3 Digital Input C4
4 Digital Input C5
5 Digital Input C6
6 Digital Input C7
LED 1 Control Indication Bit If bit =1, the function's status is selected
Dec 7644 24028 48056
RW
0 Loop 1 Auto Tune (self-tune=On, pre-tune=flashing)
Hex 1DDC 5DDC BBB8
1 Loop 1 Manual Control
2 Loop 2 Auto Tune (self-tune=On, pre-tune=flashing)
3 Loop 2 Manual Control
LED 2 Usage Value LED 2 Usage. For 8 & 9 see also LED 2 Selections.
Dec 7665 24049 48098
RW
0 Loop 1 Primary Control ON = LED 1 ON
Hex 1DF1 5DF1 BBE2
1 Loop 1 Secondary Control ON = LED 1 ON
2 Loop 2 Primary Control ON = LED 1 ON
3 Loop 2 Secondary Control ON = LED 1 ON
4 Loop 1 VMD Open ON = LED 1 ON
5 Loop 1 VMD Close ON = LED 1 ON
6 Loop 2 VMD Open ON = LED 1 ON
7 Loop 2 VMD Close ON = LED 1 ON
8
Alarm/Events/Digital/Control (Logical OR of selection
below)
9
Alarm/Events/Digital/Control inverted (Logical NOR of
selection)
Value 8 (Logical OR selection of Alarm/Events/Digital/Control) turns ON the LED if any of the selected
alarms, events, inputs or functions are active.
Value 9 (Logical NOR selection of Alarm/Events/Digital/Control) turns OFF the LED if any of the selected
alarms, events, inputs or functions are active.
Note: Pre-tune will flash the LED instead of turning it on, but flashing will be obscured if used in
conjunction with other functions when they are on.
LED 2 Alarm Indication Bit If bit =1, Alarm n status is selected
Dec 7698 24082 48164
RW
0 Alarm 1
Hex 1E12 5E12 BC24
1 Alarm 2
2 Alarm 3
3 Alarm 4
4 Alarm 5
5 Alarm 6
6 Alarm 7
