LED 2 Event Indication Bit If bit =1, Event n status is selected
Dec 7700 24084 48168
RW
0 Event 1
Hex 1E14 5E14 BC28
1 Event 2
2 Event 3
3 Event 4
4 Event 5
5 Profile Running
6 Profile End
LED 2 Slot A & Soft Input Indication Bit If bit =1, Digital A / Soft Input n status is selected
Dec 7702 24086 48172
RW
0 Digital Input A
Hex 1E16 5E16 BC2C
1 Soft Digital 1
2 Soft Digital 2
3 Soft Digital 3
4 Soft Digital 4
LED 2 Option C Digital Indication Bit If bit =1, Digital Cn status is selected
Dec 7704 24088 48176
RW
0 Digital Input C1
Hex 1E18 5E18 BC30
1 Digital Input C2
2 Digital Input C3
3 Digital Input C4
4 Digital Input C5
5 Digital Input C6
6 Digital Input C7
LED 2 Control Indication Bit If bit =1, the function's status is selected
Dec 7646 24030 48060
RW
0 Loop 1 Auto Tune (self-tune=On, pre-tune=flashing)
Hex 1DDE 5DDE BBBC
1 Loop 1 Manual Control
2 Loop 2 Auto Tune (self-tune=On, pre-tune=flashing)
3 Loop 2 Manual Control
LED 3 Usage Value LED 3 Usage. For 8 & 9 see also LED 3 Selections.
Dec 7666 24050 48100
RW
0 Loop 1 Primary Control ON = LED 1 ON
Hex 1DF2 5DF2 BBE4
1 Loop 1 Secondary Control ON = LED 1 ON
2 Loop 2 Primary Control ON = LED 1 ON
3 Loop 2 Secondary Control ON = LED 1 ON
4 Loop 1 VMD Open ON = LED 1 ON
5 Loop 1 VMD Close ON = LED 1 ON
6 Loop 2 VMD Open ON = LED 1 ON
7 Loop 2 VMD Close ON = LED 1 ON
8
Alarm/Events/Digital/Control (Logical OR of selection
below)
9
Alarm/Events/Digital/Control inverted (Logical NOR of
selection)
Value 8 (Logical OR selection of Alarm/Events/Digital/Control) turns ON the LED if any of the selected
alarms, events, inputs or functions are active.
Value 9 (Logical NOR selection of Alarm/Events/Digital/Control) turns OFF the LED if any of the selected
alarms, events, inputs or functions are active.
Note: Pre-tune will flash the LED instead of turning it on, but flashing will be obscured if used in
conjunction with other functions when they are on.
