LED 3 Alarm Indication Bit If bit =1, Alarm n status is selected
Dec 7706 24090 48180
RW
0 Alarm 1
Hex 1E1A 5E1A BC34
1 Alarm 2
2 Alarm 3
3 Alarm 4
4 Alarm 5
5 Alarm 6
6 Alarm 7
LED 3 Event Indication Bit If bit =1, Event n status is selected
Dec 7708 24092 48184
RW
0 Event 1
Hex 1E1C 5E1C BC38
1 Event 2
2 Event 3
3 Event 4
4 Event 5
5 Profile Running
6 Profile End
LED 3 Slot A & Soft Input Indication Bit If bit =1, Digital A / Soft Input n status is selected
Dec 7710 24094 48188
RW
0 Digital Input A
Hex 1E1E 5E1E BC3C
1 Soft Digital 1
2 Soft Digital 2
3 Soft Digital 3
4 Soft Digital 4
LED 3 Option C Digital Indication Bit If bit =1, Digital Cn status is selected
Dec 7712 24096 48192
RW
0 Digital Input C1
Hex 1E20 5E20 BC40
1 Digital Input C2
2 Digital Input C3
3 Digital Input C4
4 Digital Input C5
5 Digital Input C6
6 Digital Input C7
LED 3 Control Indication Bit If bit =1, the function's status is selected
Dec 7648 24032 48064
RW
0 Loop 1 Auto Tune (self-tune=On, pre-tune=flashing)
Hex 1DE0 5DE0 BBC0
1 Loop 1 Manual Control
2 Loop 2 Auto Tune (self-tune=On, pre-tune=flashing)
3 Loop 2 Manual Control
LED 4 Usage Value LED 4 Usage. For 8 & 9 see also LED 4 Selections.
Dec 7667 24051 48102
RW
0 Loop 1 Primary Control ON = LED 1 ON
Hex 1DF3 5DF3 BBE6
1 Loop 1 Secondary Control ON = LED 1 ON
2 Loop 2 Primary Control ON = LED 1 ON
3 Loop 2 Secondary Control ON = LED 1 ON
4 Loop 1 VMD Open ON = LED 1 ON
5 Loop 1 VMD Close ON = LED 1 ON
6 Loop 2 VMD Open ON = LED 1 ON
7 Loop 2 VMD Close ON = LED 1 ON
8
Alarm/Events/Digital/Control (Logical OR of selection
below)
