Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 181
9
Alarm/Events/Digital/Control inverted (Logical NOR of
selection)
Value 8 (Logical OR selection of Alarm/Events/Digital/Control) turns ON the LED if any of the selected
alarms, events, inputs or functions are active.
Value 9 (Logical NOR selection of Alarm/Events/Digital/Control) turns OFF the LED if any of the selected
alarms, events, inputs or functions are active.
Note: Pre-tune will flash the LED instead of turning it on, but flashing will be obscured if used in
conjunction with other functions when they are on.
LED 4 Alarm Indication Bit If bit =1, Alarm n status is selected
Dec 7714 24098 48196
RW
0 Alarm 1
Hex 1E22 5E22 BC44
1 Alarm 2
2 Alarm 3
3 Alarm 4
4 Alarm 5
5 Alarm 6
6 Alarm 7
LED 4 Event Indication Bit If bit =1, Event n status is selected
Dec 7716 24100 48200
RW
0 Event 1
Hex 1E24 5E24 BC48
1 Event 2
2 Event 3
3 Event 4
4 Event 5
5 Profile Running
6 Profile End
LED 4 Slot A & Soft Input Indication Bit If bit =1, Digital A / Soft Input n status is selected
Dec 7718 24102 48204
RW
0 Digital Input A
Hex 1E26 5E26 BC4C
1 Soft Digital 1
2 Soft Digital 2
3 Soft Digital 3
4 Soft Digital 4
LED 4 Option C Digital Indication Bit If bit =1, Digital Cn status is selected
Dec 7720 24104 48208
RW
0 Digital Input C1
Hex 1E28 5E28 BC50
1 Digital Input C2
2 Digital Input C3
3 Digital Input C4
4 Digital Input C5
5 Digital Input C6
6 Digital Input C7
LED 4 Control Indication Bit If bit =1, the function's status is selected
Dec 7650 24034 48068
RW
0 Loop 1 Auto Tune (self-tune=On, pre-tune=flashing)
Hex 1DE2 5DE2 BBC4
1 Loop 1 Manual Control
2 Loop 2 Auto Tune (self-tune=On, pre-tune=flashing)
3 Loop 2 Manual Control
