West Control Solutions Pro-EC44 - Page 188

Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 182
Backlight Colour Value Display Backlight Colour
Dec 7668 24052 48104
RW
0 Green to Red if any output is latched
Hex 1DF4 5DF4 BBE8
1 Red to Green if any output is latched
2 Green to Red if any alarm active
3 Red to Green if any alarm active
4 Permanent Green
5 Permanent Red
Display Language Value Select Display Language
Dec 7675 24059 48118
RW
0 Main Display Language
Hex 1DFB 5DFB BBF6
1 Alternate Display Language
Display Contrast Display Contrast Value
Dec 7676 24060 48120
RW
Screen contrast adjustment to improve clarity.
10 to 100 with 100 = maximum contrast.
Hex 1DFC 5DFC BBF8
Invert Display Value Normal Or Inverted Display
Dec 7677 24061 48122
RW
0 Normal Display
Hex 1DFD 5DFD BBFA
1 Inverted Display
Setup Lock Code Setup Mode Entry Passcode
Dec 7678 24062 48124
RW
1 to 9999. Default is 10
Hex 1DFE 5DFE BBFC
Configuration Lock Code Configuration Mode Entry Passcode
Dec 7679 24063 48126
RW
1 to 9999. Default is 10
Hex 1DFF 5DFF BBFE
Tuning Lock Code Automatic Tuning Mode Entry Passcode
Dec 7680 24064 48128
RW
1 to 9999. Default is 10
Hex 1E00 5E00 BC00
Supervisor Lock Code Supervisor Mode Entry Passcode
Dec 7681 24065 48130
RW
1 to 9999. Default is 10
Hex 1E01 5E01 BC02
Profiler Setup Lock Code Profiler Setup Mode Entry Passcode
Dec 7682 24066 48132
RW
1 to 9999. Default is 10
Hex 1E02 5E02 BC04
USB Lock Code USB Mode Entry Passcode
Dec 7683 24067 48134
RW
1 to 9999. Default is 10
Hex 1E03 5E03 BC06
Recorder Lock Code Recorder Control Mode Entry Passcode
Dec 7684 24068 48136
RW
1 to 9999. Default is 10
Hex 1E04 5E04 BC08
Profile Control Lock Code Profile Control Mode Entry Passcode
Dec 7688 24072 48144
RW
1 to 9999. Default is 10
Hex 1E08 5E08 BC10
Read Only Operation Mode Value Read Only Operation Mode
Dec 7685 24069 48138
RW
0 Operation Mode Read/Write
Hex 1E05 5E05 BC0A
1 Operation Mode Read Only
