Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-2 September 2014 Page 183
Loop 1 Trend View Sample Rate Value Trend Sample Interval For Loop 1
Dec 9000 25384 50768
RW
0 Every Second
Hex 2328 6328 C650
1 Every 2 Seconds
2 Every 5 Seconds
3 Every 10 Seconds
4 Every 15 Seconds
5 Every 30 Seconds
6 Every Minute
7 Every 2 Minutes
8 Every 5 Minutes
9 Every 10 Minutes
10 Every 15 Minutes
11
Every 30 Minutes
Loop 1 Trend View Data Value Values To Display In Loop 1 Trend View
Dec 9001 25385 50770
RW
1 Process variable only
Hex 2329 6329 C652
2 Process variable and setpoint
3 Max & min process value since last sample
Loop 1 Trend View in Operator Mode Value Trend View For Loop 1 Visible In Operator Mode
Dec 9007 25391 50782
RW
0 No
Hex 232F 632F C65E
1 Yes
Loop 2 Trend View Sample Rate Value Trend Sample Interval For Loop 2
Dec 9010 25394 50788
RW
0 Every Second
Hex 2332 6332 C664
1 Every 2 Seconds
2 Every 5 Seconds
3 Every 10 Seconds
4 Every 15 Seconds
5 Every 30 Seconds
6 Every Minute
7 Every 2 Minutes
8 Every 5 Minutes
9 Every 10 Minutes
10 Every 15 Minutes
11
Every 30 Minutes
Loop 2 Trend View Data Value Values To Display In Loop 2 Trend View
Dec 9011 25395 50790
RW
1 Process variable only
Hex 2333 6333 C666
2 Process variable and setpoint
3 Max & min process value since last sample
Loop 1 Trend View in Operator Mode Value Trend View For Loop 2 Visible In Operator Mode
Dec 9017 25401 50802
RW
0 No
Hex 2339 6339 C672
1 Yes
