User Guide
1. Overview
1.16 SAS Cabling
Type Length Manufacturer Vendor Part Number
Amphenol ICC (FCI) FOHHB23P000055m
Molex 106415-2105
6m Amphenol ICC (FCI) FOHHB23P00006
10m Molex 106415-2110
1m Amphenol ICC (FCI) 10112041-2010LF
Amphenol ICC (FCI) 601760006
CS Electronics 12G-HD-4444/2M
Data Storage Cables (DSC) C5555-2M
The Mate Company (TMC) C5555-2M
10112041-2020LFAmphenol ICC (FCI)
10117949-2020LF
2m
Molex 1110751002
Amphenol ICC (FCI) 601760008
CS Electronics 12G-HD-4444/3M
10112041-2030LFAmphenol ICC (FCI)
10117949-4030LF
Passive
HD Mini-SAS to HD Mini-SAS
6
3m
Molex 1110751003
Active Cables
When daisy-chaining multiple Ultrastar Data60 enclosures together, active cables must be used between
enclosures for improved signal integrity.
Passive Cabling
As a best practice, Western Digital requires connecting the cables to every other SAS connector port when
connecting more than one host per IOM. Please refer to Table 22: Recommended IOM Port Connection
Order (page 21) for port connection ordering required for IOMA and IOMB:
6. Passive cables should only be used for direct (host-to-enclosure) connections.
