page Appendix – 2
D-5000 / May 2000
APPENDIX
D-5000 / Feb 2005
REPLACEMENT PARTS — D-5000 AUDIO CONSOLE
COMPONENT DESCRIPTION
WS P/N
SLD-600 ADC MODULE COMPLETE ANALOG STEREO LINE INPUT MODULE
"001700"
SLD-600SRC MODULE COMPLETE DIGITAL STEREO INPUT MODULE WITH SAMPLE RATE CONVERTER
"001703"
SLADC-600 CARD A-TO-D CONVERTER DAUGHTER BOARD FOR ANALOG STEREO LINE INPUTS
"001756"
SRC-500 CARD SAMPLE RATE CONVERTER CARD FOR DIGITAL INPUTS
"001543"
MMD-600 MODULE COMPLETE MONO MIC INPUT MODULE
"001719"
OMD-600/1 MODULE COMPLETE PROGRAM/ AUX OUTPUT MODULE
"001705"
OMD-600/2 MODULE COMPLETE AUDITION/ UTILITY OUTPUT MODULE
"001706"
MOD-600 MODULE COMPLETE METER OUTPUT DRIVER MODULE
"001707"
CRD-600 MODULE COMPLETE CONTROL ROOM MONITOR MODULE
"001708"
LSD-600 MODULE COMPLETE LINE SELECT CONTROL MODULE (CONTROLS LSR-500)
"001709"
LSR-500 RACKMOUNT UNIT COMPLETE RACKMOUNT LINE SELECTOR UNIT (CONTROLLED BY LSD-600)
"001510"
LSA-600 MODULE COMPLETE ANALOG LINE SELECT MODULE
"001710"
SCD-600 MODULE COMPLETE STUDIO MONITOR MODULE
"001711"
CPU-600 MODULE COMPLETE CONSOLE CPU MODULE
"001712"
SPD-600 MODULE COMPLETE PHONE MODULE
"001713"
DSP-600 MODULE COMPLETE CONSOLE DSP MODULE
"001714"
TRD-600 FF MODULE COMPLETE FULL-FUNCTION TAPE REMOTE CONTROL MODULE
"001715"
TRD-600 SS MODULE COMPLETE START/STOP TAPE REMOTE CONTROL MODULE
"001717"
ICMD-600 MODULE COMPLETE INTERCOM MODULE
"001716"
MCLK-600 CARD MASTER CLOCK DRIVER/BUFFER CARD
"001758"
SCLK-600 CARD SLAVE CLOCK BUFFER CARD
"001759"
MANUAL OWNER'S MANUAL
"008213"
CLK/TMR-5000 CLOCK AND EVENT TIMER ASSEMBLY
"001836"
PSC-D340 POWER SUPPLY CONSOLE POWER SUPPLY
"007220"
CABLE CONSOLE POWER SUPPLY CABLE
"007021"
WIRED REPLACEMENT FADER WIRED FADER FOR SLD-600 & MMD-600 MODULES
"051500"
WIRED REPLACEMENT FADER WIRED FADER FOR SPD-600 MODULES
"051501"
WIRED REPLACEMENT SWITCH WIRED "ON/OFF" SWITCH
"051502"
WIRED REPLACEMENT POT WIRED POT FOR CONTROL ROOM AND HEADPHONE MONITOR
"051503"
I/O CONNECTOR DB-25 CONNECTOR FOR MODULE I/O CONNECTIONS
"200022"
HOOD HOOD FOR MODULE I/O DB-25 CONNECTORS
"200025"
REPLACEMENT SWITCH "ON/OFF" SWITCH
"510112"
REPLACEMENT RED BUTTON MODULE "ON" BUTTON
"530101"
REPLACEMENT YELLOW BUTTON MODULE "OFF" BUTTON
"530102"
RED LED LAMP REPLACEMENT MODULE "ON" LED LAMP
"600026"
REPLACEMENT VU LED CARD LED-3
"007104"
REPLACEMENT METER CONSOLE VU METER
"630004"
YELLOW LED LAMP REPLACEMENT MODULE "OFF" LED LAMP
"600030"
REPLACEMENT CUE SPEAKER REPLACEMENT CUE SPEAKER
"960000"
