Wheatstone D-5000 - Output Modules (Omd-600); Default Chapter; DB Connector Pinout Drawings

page 4 – 1
D-5000 / May 2000
OUTPUT MODULES
Output Modules
(OMD-600)
Chapter Contents
Module Overview........................................................................ 4-2
Internal Programming Options ................................................. 4-3
Insert Bypass .......................................................................................................... 4-3
Hook-ups..................................................................................... 4-3
Master Output Module A (PGM and AUX)
Upper DB-25 Connector — Analog Audio ....................................................... 4-3
Lower DB-25 Connector — Digital Outputs..................................................... 4-4
Master Output Module B (AUD and UTL)
Upper DB-25 Connector — Analog Audio ....................................................... 4-4
Lower DB-25 Connector — Digital Outputs..................................................... 4-5
DB Connector Pinout Drawings
Master Output A...................................................................................................... 4-6
Master Output B...................................................................................................... 4-7
