LINE PRESELECTOR MODULE
Line Preselector Module-
Analog
(LSA-600; optional)
Overview
This optional module electronically selects one of seven stereo line
sources and routes it to one stereo output, allowing you to expand the
source capability of an input channel or monitor module.
All audio input and output signals are made via two multipin DB-25
connectors mounted in the bottom of the console’s mainframe, directly
underneath this module.
3
7
4
OFF
2
6
1
5
SOURCE
PRESELECT
