MONO MIC INPUT
MMD-600 Mono Mic Input
DB Connector Pinouts
ANALOG
I/O PORTS
(
Upper DB-25)
LOGIC
I/O PORTS
(Lower DB-25)
MIC A IN SH
MIC A IN HI
MIC B IN LO
AUDIO GROUND
N/C
N/C
AUDIO GROUND
N/C
N/C
INSERT OUT SH
INSERT OUT HI
INSERT IN LO
AUDIO GROUND
MIC A IN LO
MIC B IN SH
MIC B IN HI
N/C
AUDIO GROUND
N/C
N/C
AUDIO GROUND
N/C
INSERT OUT LO
INSERT IN SH
INSERT IN HI
N/C
N/C
DIGITAL GROUND
REMOTE ON B
ON TALLY B
TB TO CR B
N/C
N/C
DIGITAL GROUND
REMOTE ON A
ON TALLY A
TB TO CR A
AUDIO GROUND
N/C
+5V DIGITAL
DIGITAL GROUND
REMOTE OFF B
OFF TALLY B
COUGH B
N/C
+5V DIGITAL
DIGITAL GROUND
REMOTE OFF A
OFF TALLY A
COUGH A
5
4
3
2
1
17
16
15
14
8
7
6
20
19
18
10
9
23
22
21
13
12
11
25
24
5
4
3
2
1
17
16
15
14
8
7
6
20
19
18
10
9
23
22
21
13
12
11
25
24
