page 9 – 7
D-5000 / July 2000
V I R T U A L D I P S W I T C H
In a similar fashion, your mouse can be used to alter the console mutes
and other settings by clicking on the function to enable it on source “A”,
“B”, both, or neither. Once you have finished setting the text and configu-
ration that you wish for an input channel, you send the information to the
console by selecting “Write Current” under the “Slot” menu (figure 6).
The information is then sent to the console, and the input channel display
will be updated to the text you chose. To select another input channel to
modify, choose its corresponding slot number from the selection bar near
the top of the status display screen. The status screen will change to show
the type and settings of the module in the slot you have selected.
Figure 6
