Wall standpipe drain system
Laundry tub drain system
4
1
/2"
(113 mm)
Floor standpipe drain system
4
1
/2"
(113 mm)
30"
(762 mm)
min.
4
1
/2"
LOCATION REQUIREMENTS
Proper installaon is your responsibility.
You will need:
�
A water heater set to 120° F (49° C).
�
A grounded electrical outlet located within 6 (1.8 m) of
power cord on back of washer.
�
Hot and cold water faucets located within 4 (1.2 m) of hot
20-100 psi (137.9-689.6 kPa).
�
washer. Installing on carpet or surfaces with foam backing is
not recommended.
�
Floor must support washer’s total weight (with water and load)
of 315 lbs (143 kgs).
IMPORTANT: Do not install, store or operate washer where
it will be exposed to weather or in temperatures below 32° F
(0° C). Water remaining in washer aer use may cause damage
in low temperatures. See “Washer Care” in Washer Use and Care
Guide for winterizing informaon.
All dimensions show recommended spacing allowed, except for
closet door venlaon openings which are the minimum required.
For each arrangement, consider allowing more space for ease of
installaon and servicing, and spacing for companion appliances
Space must be large enough to allow door to fully open.
Add spacing of 1" (25 mm) on all sides of washer to reduce
noise transfer. If a closet door or louvered door is installed, top
and boom air openings in door are required.
31
1
/
2
"
(800 mm)
27"
(686 mm)
38"
(965 mm)
51"
(1295 mm)
1"
(25 mm)
1"
(25 mm)
39" min.
(990 mm)
Custom under counter installaon:
7"
(178 mm)
14"
(356 mm)
1"
(25 mm)
4"
(102 mm)
1"
(25 mm )
Custom cabinet installaon:
Recessed area or closet installaon (washer only):
34" min.
(864 mm )
1"
(25 mm)
4"
(102 mm)
24 in.
2
(155 cm
2
)
48 in.
2
(310 cm
2
)
3"
(76 mm)
3"
(76 mm)
1"
(25 mm)
1"
(25 mm)
5"
(127 mm)
24 in .
2
(155 cm
2
)
48 in .
2
(310 cm
2
)
3"
(76 mm)
3"
(76 mm)
77
1
/2"
(1969 mm)
6"
(152 mm)
1"
(25 mm)
Recessed area or closet installaon
(stacked washer and dryer):
